Description
Hot sandwiches, pastries and snacks in seconds, from a 16-11/16" wide oven with no hood.
The UNOX XAMA-01NS-MCDS SPEED.Compact ECO combines microwaves with hot airflow to reheat and finish baked goods, snacks and leavened items fast. It is 16-11/16" wide, plugs into a 208V or 240V NEMA 6-15P receptacle, and needs no water line. Unox says it was tested and approved by Intertek for ventless operation under UL 710B and EPA 202, for all foods except fatty raw proteins, so cafes, convenience stores and bars can usually run it without a hood.
Will it fit · Will it plug in
- Outside size
- 16-11/16" W × 28-5/16" D × 24-1/4" H overall (body 23-5/8" deep, Unox drawing)
- Door
- Drop-down door at the front
- Inside
- One 11.8" x 11.8" tray; chamber 12-3/8" W × 12-5/8" D × 8-1/4" H; max food load 7 lb
- Power
- 208V or 240V single-phase, 60 Hz, 3.6 kW, 14.5 A max
- Breaker and plug
- 15 A breaker; H07RN-F cord, 3 x AWG 14, NEMA 6-15P plug
- Water and drain
- None needed
- Ventilation
- Ventless approved (Intertek, UL 710B / EPA 202) except fatty raw proteins such as chicken, raw bacon, raw sausage and steaks
- Net weight
- 132 lbs
If you will cook fatty raw proteins, check local HVAC codes and your inspector about ventilation, as Unox advises.
Microwave plus air
SPEED.Plus spreads 1 kW of microwave energy evenly while hot air browns and crisps.
Ready out of the box
No exhaust pipes, hoods or water connection; chamber-and-chimney catalysts reduce smoke, noise and odor.
Easy programs
384 speed programs, 10 favorites and one-touch CLICK&COOK on a 9.5" touch panel.
Saves energy
SMART.Energy drops to stand-by when the chamber is empty; rock wool insulation keeps heat in.
Delivery and setup
- Free shipping on this item. See our shipping policy for delivery details.
- Usually ships in 1 business day.
- Covered by our Best Price Guarantee: call (201) 467-8222 if you find a lower price.
- Have an electrician install a NEMA 6-15P receptacle on a 15 A, 208V or 240V circuit before delivery.
- Optional accessories (SPEED.Bake tray, SPEED.Marks tray, storage top, QUICK.Rinse) are sold separately.
- Inspect the shipment before signing for it and note any damage with the carrier.
Questions buyers ask
Does it need a hood?
Unox says the SPEED.Compact was tested and approved by Intertek for ventless operation (UL 710B, EPA 202) for all foods except fatty raw proteins such as chicken, raw bacon, raw sausage and steaks. For those, check local HVAC codes.
What outlet does it need?
A NEMA 6-15P receptacle on a 15 A breaker, 208V or 240V single-phase. It draws up to 14.5 A at 3.6 kW.
How much fits inside?
One 11.8" x 11.8" tray; the chamber is 12-3/8" W x 12-5/8" D x 8-1/4" H and takes up to 7 lb of food.
How hot does it get?
From 86°F up to 536°F, with up to 9 cooking steps and 1 kW of microwave power.
Does it need water?
No. Unox lists no water or drain connection.
What does the warranty cover?
Unox USA covers labor for 12 months and parts for 24 months from the dealer invoice or installation date, whichever is earlier.
When will it ship, and do you match lower prices?
UNOX items usually ship in 1 business day, shipping is free on this item, and it is covered by our Best Price Guarantee. Call (201) 467-8222 if you find a lower price.
Specs
| Manufacturer | UNOX |
|---|---|
| Model Number | XAMA-01NS-MCDS |
| Series | SPEED.Compact ECO |
| Type | Microwave Convection Speed Oven |
| Quantity | 1/Each |
| Net Weight | 132 lbs |
| Width | 16-11/16 Inches (424 mm) |
| Depth | 28-5/16 Inches (719 mm) Overall23-5/8 Inches Body |
| Height | 24-1/4 Inches (616 mm) |
| Chamber | 12-3/8" W x 12-5/8" D x 8-1/4" H (315 x 320 x 210 mm) |
| Tray Size | 1 Tray 11.8" x 11.8" |
| Door | Drop-Down Opening |
| Voltage | 208 / 240 Volts |
| Phase | Single Phase |
| Hertz | 60 |
| Total Power | 3.6 kW |
| Microwave Power | 1 kW |
| Max Amp Draw | 14.5 Amps |
| Breaker Size | 15 A |
| Power Cable | H07RN-F, 3 x AWG 14 |
| Plug Type | NEMA 6-15PCord Connected |
| RCD / GFCI | Type A |
| Temperature Range | 86 - 536 Degrees F |
| Max Food Load | 7 lbs (3 kg) |
| Programs | 384 Speed Programs10 FavoritesUp to 9 Steps |
| Controls | 9.5" Touch Control Panel |
| Connectivity | Wi-Fi 2.4 GHzUSB |
| Chamber | AISI 304 Stainless Steel |
| Insulation | Rock Wool Mineral Insulation |
| Emissions | Chamber and Chimney Catalysts |
| Water Connection | None |
| Certifications | cETLusNSFKosher (Unox 2026 Spec Sheet) |
| Ventless | Intertek Tested to UL 710B / EPA 202 (Except Fatty Raw Proteins) |
| IP Rating | IPX4 |
| Warranty | 12 Months Labor, 24 Months Parts (Unox USA) |
| Usage | Commercial Use Only |
