Description
Simmer sauces, boil stock and sauté on four solid electric burners where you have no gas line.
The Pegasus HP-24E is a 24" countertop electric range for restaurants, caterers, food trucks and kitchens without gas. It has four spill-proof 9" solid cast-iron alloy burners at 2 kW each, with six-position controls that go from simmer to boil, and every element has built-in overheat protection. It runs on 8 kW at 208V, 3-phase or 1-phase after a field conversion.
Will it fit · Will it plug in
- Outside size
- 24.1" W × 34.9" D × 13.4" H
- Crated size
- 31.49" W x 19.68" H x 37.79" D, 84 lb
- Power
- 208V, 60 Hz, 8 kW: 3-phase 25.0 / 25.0 / 16.7 A per line, or 38.5 A on 1-phase
- Clearances
- Non-combustible walls: 0" left, 0" right, 2" back. Combustible walls: 1" left, 3" right, 3" back
The spec sheet lists no cord or plug, so plan for an electrician to connect it to a 208V circuit. It sits on a counter or equipment stand; at 34.9" deep, check that your counter is deep enough. Your local code may require a ventilation hood.
Solid 9" burners
Spill-proof cast-iron alloy plates heat evenly for soups, sauces, stews and sautéing.
Six heat settings
Each burner has its own six-position control, from a simmer to a full boil.
Overheat protection
Every heating element has a built-in thermo-protection device.
Heavy-duty build
Stainless steel body on adjustable legs for a level cooking surface.
Delivery and setup
- Ships by freight carrier at 84 lb. Inspect it for damage before you sign for it.
- Have a licensed electrician connect it to 208V power.
- See our shipping policy for delivery options, including pickup at our Kearny, NJ warehouse.
Questions buyers ask
What power does it need?
208V, 60 Hz, 8 kW. On 3-phase it draws 25.0 / 25.0 / 16.7 A per line; on 1-phase it draws 38.5 A. It is field convertible from 3-phase to 1-phase.
What size are the burners?
4 solid 9" cast-iron alloy burners, 2 kW each.
Do I need special pans?
No. Solid electric burners heat any flat-bottomed pot or pan; flat bottoms make the best contact.
How close can it go to a wall?
Against non-combustible walls it needs 0" on the sides and 2" at the back. Against combustible walls it needs 1" on the left and 3" on the right and back.
What does the warranty cover?
Pegasus gives a one-year limited parts and labor warranty in the USA and Canada.
Specs
| Manufacturer | Pegasus |
|---|---|
| Model Number | HP-24E |
| Shipping Weight | 84 lbs |
| Width | 24.1 Inches |
| Depth | 34.9 Inches |
| Height | 13.4 Inches |
| Shipping Dimensions | 31.49" W x 19.68" H x 37.79" D |
| Burners | 4 solid 9" cast-iron alloy burners, 2 kW each |
| Controls | Six-position temperature control per burner (simmer to boil) |
| Safety | Built-in thermo-protection on each heating element |
| Power Type | Electric |
| Wattage | 8 kW |
| Voltage | 208 Volts |
| Phase | 3 Phase, field convertible to 1 Phase |
| Amps | 25.0 / 25.0 / 16.7 A (208V 3-phase, per line)38.5 A (208V 1-phase) |
| Hertz | 60 Hz |
| Construction | Heavy-duty stainless steel |
| Legs | Adjustable |
| Clearance, Non-Combustible | Left 0"Right 0"Back 2" |
| Clearance, Combustible | Left 1"Right 3"Back 3" |
| Certifications | cETLusETL SanitationCE |
| Warranty | One-year limited parts and labor (USA and Canada only) |
| Usage | Commercial |
