Description
A 8 ft gravity coil service case that keeps fresh meat, deli and seafood moist and on display.
The Atlantic Fargo VFA45G-8 is a remote gravity coil service case for butcher counters, delis and seafood departments. It is 8'-5" (101") long, 45" deep and 57" tall. A gravity coil cools the display from above without blowing air across the product, and a low-speed fan coil cools the base storage. Product holds at an adjustable 30°F to 41°F.
Will it fit · Will it plug in
- Outside size
- 101" L × 45" D × 57" H (the drawing shows 4'-10", 58", overall height)
- Length
- 8'-5" = 101"
- Counter height
- 36" (3', per drawing)
- Power
- 120V / 1-phase, 1.7 amps
- Refrigeration
- Remote: 8,185 BTU/h at 23°F evaporator, R404A
- Connections
- 5/8 suction, 3/8 liquid; solenoid valve not included
Plan for 58" of height. Measure every doorway and turn on the delivery path; the case's smallest outside dimension is its 45" depth.
Gravity coil display
Cold air falls gently from the gravity coil, so meat and seafood dry out less than in a fan-forced case.
Cold storage below
A low-speed fan coil cools the base storage, so back-up product stays next to the display.
Food-safe build
304 stainless steel on every food-contact surface, tempered glass and a heavy-duty structure.
Easy to see, easy to serve
Double front glass limits condensation, LED lighting shows the product, and rear sliding glass doors give staff access.
Remote refrigeration
A 8,185 BTU/h case load on R404A at a 23°F evaporator, with no compressor in the case.
Delivery and setup
- Free shipping on this item.
- Ships by freight carrier. Inspect the case for damage before you sign for it.
- A licensed refrigeration technician connects it to your remote condensing unit or rack, the refrigerant lines and a drain.
- The solenoid valve is not included; your refrigeration contractor supplies it.
- See our shipping policy for delivery options, including pickup at our Kearny, NJ warehouse.
Questions buyers ask
Does it have its own compressor?
No. It is a remote case: it connects to a separate condensing unit or rack through 5/8 suction and 3/8 liquid lines. The case load is 8,185 BTU/h at a 23°F evaporator temperature with R404A. The solenoid valve is not included.
What power does the case need?
120V, 1-phase at 1.7 amps for the fans, lights and controls. The compressor is powered at the remote system.
What temperature does it hold?
An adjustable 30°F to 41°F, set on the digital thermostat.
Why a gravity coil?
The gravity coil cools by letting cold air fall over the product instead of blowing it, which helps fresh meat and seafood keep their moisture. A low-speed fan coil cools the base storage.
Will it fit through my door?
The case is 101" L × 45" D × 57" H (the drawing shows 58" overall). Its smallest dimension is the 45" depth, so measure every doorway and turn before ordering.
What store conditions does it need?
The manufacturer rates these cases for stores at or below 77°F and 60% relative humidity. Warmer or more humid stores make the case work harder.
What other lengths are there?
The Fargo line is listed as the VFA45G-4, VFA45G-8 and VFA45G-12. Call us to compare sizes.
Key Features
- 8'-5" (101") L x 45" D x 57" H
- Two coils: gravity coil on top, low-speed fan coil for the base and cold storage
- Adjustable 30°F to 41°F with a digital thermostat
- Remote refrigeration: 8,185 BTU/h load, R404A, 23°F evaporator
- 120V / 1-phase, 1.7 amps
- 304 stainless steel on all food-contact surfaces
- Double front glass, tempered glass and rear double glass sliding doors
Specifications
| Manufacturer | Atlantic |
|---|---|
| Model Number | VFA45G-8 |
| Series | Fargo Gravity Coil Service Case |
| Equipment Type | Remote Gravity Coil Deli/Meat Service Case |
| Application | Deli, Meat and Seafood |
| Nominal Length | 8 Feet |
| Length | 8'-5" (101 Inches) |
| Depth | 45 Inches |
| Height | 57 Inches (drawing: 4'-10" / 58 Inches) |
| Counter Height | 36 Inches (per drawing) |
| Evaporator Fans | 4 |
| Electrical | 120 Volts / 1 Phase, 1.7 Amps |
| Refrigeration | Remote: gravity coil + low-speed fan coil |
| Refrigeration Load | 8,185 BTU/H |
| Evaporator Temperature | 23 Degrees F |
| Refrigerant | R404A |
| Defrost | Timed-Off |
| Suction Line | 5/8 |
| Liquid Line | 3/8 |
| Solenoid Valve | Not included |
| Temperature Range | 30 - 41 Degrees F |
| Controls | Digital thermostat |
| Shelves | Base + 1 (refrigerated, adjustable shelf) |
| Food-Contact Surfaces | 304 stainless steel |
| Front | Double front glass, tempered |
| Rear | Double glass sliding doors with frame |
| Lighting | LED (T8 4000K) on canopy and shelf |
| Cold Storage | Refrigerated storage in the base |
| Store Conditions | Up to 77 Degrees F and 60% relative humidity |
