Description
The Traulsen RLT232WUT-FHS is a 58-inch-wide, two-section reach-in freezer with two full-height solid doors. Its top-mounted, self-contained refrigeration system keeps the condenser and refrigeration components within the cabinet, making it a practical choice where a separate remote refrigeration system is not planned.
This R-Series configuration has a stainless steel exterior and interior, six adjustable coated-wire shelves, interior LED lighting, and locking doors. Full-height doors provide a tall 57 9/16-inch clear door opening for organizing bulk frozen ingredients, prepared items, and boxed inventory on each section’s shelves.
Applications and Workflow
Suitable for commercial kitchens, commissaries, bakeries, and institutional foodservice operations that need upright frozen storage in a two-section footprint. This is a freezer, with a standard operating range of 0°F to -5°F; it is not intended to serve as a refrigerator. Plan aisle space for the doors and do not block the top-mounted refrigeration area.
Features and Practical Benefits
Full-height access in two sections
Two full-height solid doors provide a 57 9/16-inch clear door height, giving staff access to tall shelf openings while allowing the cabinet to be organized by section.
Self-contained top-mounted refrigeration
The balanced refrigeration system is top mounted and self-contained, so this model does not require a separately installed remote condenser system.
Six adjustable shelves included
The standard interior arrangement includes three adjustable coated-wire shelves per section, for six shelves total. Shelf positions can be adapted to the product mix.
Designed for active kitchen workflow
Self-closing doors can stay open at 120 degrees during loading, while LED lighting activates automatically when the doors are opened.
Stainless steel R-Series interior
This R-Series model combines a stainless steel exterior with a stainless steel interior for a durable storage cabinet finish.
Technical Specifications
| Manufacturer model | RLT232WUT-FHS |
|---|---|
| Cabinet configuration | Two-section reach-in freezer with full-height solid doors |
| Net capacity | 50.53 cu. ft. |
| Overall width | 58 in. |
| Overall depth | 35 1/8 in. |
| Depth with door open 90 degrees | 56 11/16 in. |
| Clear door width | 20 15/16 in. |
| Clear full-door height | 57 9/16 in. |
| Standard shelves | 6 |
| Electrical service | 115/60/1 |
| Plug type | NEMA 5-20P |
| Full-load amperage | 13.5 A |
| Refrigerant | R290 |
| Refrigerant charge | 4.5 oz. (127 g) |
| Compressor rating | 1 1/4 HP |
| Standard operating temperature | 0°F to -5°F |
| Supplied legs | Four 6 in. adjustable stainless steel legs |
| Recommended top clearance | 12 in. |
Installation and Purchasing Considerations
- Allow a 58-inch overall width and 35 1/8-inch overall depth for the cabinet. The cabinet is 83 7/16 inches high on its supplied 6-inch adjustable stainless steel legs.
- When either full-height door is open 90 degrees, depth reaches 56 11/16 inches. Maintain clear aisle space so doors can open and staff can load shelves safely.
- This model operates on 115/60/1 power and is equipped with a NEMA 5-20P plug on a 9-foot cord. Confirm that the installation location has the matching electrical receptacle.
- Provide 12 inches of top clearance where possible for refrigeration performance and service access. The refrigeration system is top mounted, so do not obstruct its upper service and airflow area.
- The standard cabinet support is four 6-inch adjustable stainless steel legs. Casters and other support arrangements are listed as options, not standard equipment.
Choosing This Configuration
This exact RLT232WUT-FHS configuration is the R-Series, self-contained version with two full-height solid doors. It is not the half-height-door configuration, which uses four half doors.
The R-Series has a stainless steel interior. The related A-Series configuration uses an anodized aluminum interior.
The listed standard shelf arrangement is six coated-wire shelves total. Trayslides, additional shelves, stainless steel shelves, casters, and alternate electrical arrangements are options and should be specified separately if needed.
Frequently Asked Questions
What electrical connection does the RLT232WUT-FHS use?
It uses 115/60/1 electrical service and comes with a NEMA 5-20P plug on a 9-foot cord.
How many shelves are supplied?
Six adjustable coated-wire shelves are standard: three shelves per section. They are factory installed on shelf pins.
How much space is needed with the doors open?
The cabinet is 35 1/8 inches deep closed and measures 56 11/16 inches deep with a door open 90 degrees. Each full-height door has a 20 15/16-inch clear width.
What freezer temperature range is specified?
The standard operating temperature is 0°F to -5°F. The cabinet is also specified as capable of -10°F operation in ambient temperatures up to 100°F.
