A 5' x 8' walk-in freezer box with an insulated floor, ready for frozen stock in restaurants and stores.
The Astra AFWF5X8 is a 5' x 8' walk-in freezer box for restaurants, pizzerias, ice cream shops, grocery stores and caterers that have outgrown reach-in freezers. It measures 4' 11" x 8' 2" outside and 7' 7" tall, with a 4' 3" x 7' 6" floor inside. The walls are 4" foamed-in-place polyurethane panels that lock together with cam-locks. This listing is the box only: pick Top Mount or Remote Turbo Air refrigeration above, or use your own.
Measure the floor space, the ceiling height and the delivery path before ordering. A top-mount unit sits on the roof and adds height, so call us with your ceiling height if you choose Top Mount.
A 24 ga. steel floor rated 600 lb/sq. ft. for foot traffic; add diamond plate for hand trucks or pallet jacks.
Foamed-in-place polyurethane, CFC and HFC free, with tongue-and-groove edges and cam-lock joints.
24 ga. pre-painted white galvanized steel skins inside and out.
Self-closing, spring-loaded hinges, a flush-mounted door, a keyed locking handle and a 120V door heater wire, plus a pressure relief vent for the freezer.
Choose a Turbo Air Top Mount package unit on the roof (R290, hot gas defrost) or a Remote condensing unit and evaporator in the Refrigeration option above.
Choose Outdoor to add the rain roof cover for an outdoor installation.
No. The AFWF5X8 is the box only. Choose Top Mount (Turbo Air Smart 7 package unit on the roof, 7,000 BTU, R290) or Remote (a Turbo Air 2 HP outdoor condensing unit with a 7,200 BTU evaporator) in the Refrigeration option above.
A freezer needs an insulated floor to keep the cold in and protect the slab underneath. The floor is 24 ga. steel rated 600 lb/sq. ft. for foot traffic; add diamond plate for carts.
The 30" x 77" door is standard and the 36" door costs nothing extra. A 48" x 77" pallet door is available for an added charge when you move pallets or wide racks.
Yes, with the Outdoor option, which adds a rain roof cover. Talk to us about outdoor-rated refrigeration before ordering.
The box needs 120V for the door heater wire (1A) and the light. Top Mount refrigeration runs on 208-230V single phase; Remote needs 208-230V single phase at the condensing unit. Have an electrician confirm your circuits.
Panels have a 10-year warranty and parts have 1 year. Top Mount refrigeration has 1 year parts and labor, Remote has 1 year parts, and an additional 4 years is available for both.
Keyed Locking Door Handle
Heavy-Duty Door Hinge
Self-Closing Door Mechanism
Vapor Proof Light
LED Light
Exterior Ramp
Aluminum Diamond Plate
Kick Plate
