Description
Advance Tabco 19-18-72-ADA-F — Commercial Hand Wash Sinks
The Advance Tabco 19-18-72-ADA-F is offered in the configuration shown below. Overall dimensions: 72 in. W × 19.5 in. D × 25.5 in. H. Review the construction, included components and manufacturer specifications to confirm the fit for your installation.
Product Features
- Wall‑mounted 72" W × 19½" D × 25½" H overall size with a 16" × 5" bowl for high‑volume use.
- Three 8½" gooseneck wrist‑handle faucets (K‑161‑LU) provide easy, hygienic operation at each station.
- Built from 16‑gauge 304 stainless steel with TIG‑welded tubular supports for corrosion resistance.
- 8½" high backsplash and punched 8" O.C. faucet holes protect the wall and simplify cleaning.
- ADA compliant with 5" bowl depth and includes a 3½" rear basket drain for accessible hand washing.
Technical Specifications
| Manufacturer | Advance Tabco |
|---|---|
| Model Number | 19-18-72-ADA-F |
| Shipping Weight (Supplier Reference) | 95 lbs |
| Width | 72 in. |
| Depth | 19.5 in. |
| Height | 25.5 in. |
| Style | wall mounted |
| Bowl Width (left to right) | 20" & up |
| Bowl Depth (front to back) | 15" - 19" front-to-back |
| Bowl Height (rim to drain) | 5" deep |
| Faucet | faucet included |
Installation and Configuration
Check the manufacturer specification sheet for installation requirements, dimensions and connections. Optional accessories are sold separately unless identified as included in the product features.
Documents and Resources
Available documents: Spec Sheet. Open the product documents section to view or download the manufacturer PDFs.
