Description
Advance Tabco 9-OP-24FM-FGR — Commercial Mop Sinks
The Advance Tabco 9-OP-24FM-FGR is offered in the configuration shown below. Overall dimensions: 21.38 in. W × 24 in. D × 28 in. H. Review the construction, included components and manufacturer specifications to confirm the fit for your installation.
Product Features
- Mop sink
- flush-with-floor (recessed into floor)
- 21-3/8"W x 24"D x 10" deep bowl
- with 16-1/2" tall rear & right side splashes (above floor)
- with removable fiberglass subway grating
- allows mop buckets to roll over sink at floor level
- removable stainless steel strainer basket
- 4" O.D. waste pipe 3" tall
Technical Specifications
| Manufacturer | Advance Tabco |
|---|---|
| Model Number | 9-OP-24FM-FGR |
| Shipping Weight (Supplier Reference) | 120 lbs |
| Width | 21.38 in. |
| Depth | 24 in. |
| Height | 28 in. |
| Overall Width (side - side) | 21" - 24" |
| Style | floor mounted |
| Backsplash | back & right splashes |
| Construction | stainless steel |
| Bowl Height | 10" deep |
| Bowl Width (left to right) | 21" |
| Bowl Depth | 24" front-to-back |
| Special Features | fiber glass grating |
Installation and Configuration
Check the manufacturer specification sheet for installation requirements, dimensions and connections. Optional accessories are sold separately unless identified as included in the product features.
Documents and Resources
Available documents: Spec Sheet. Open the product documents section to view or download the manufacturer PDFs.
