Advance Tabco PRD-24-36 — Underbar Drainboard & Filler Boards
The Advance Tabco PRD-24-36 is offered in the configuration shown below. Overall dimensions: 36 in. W × 25 in. D × 36 in. H. Review the construction, included components and manufacturer specifications to confirm the fit for your installation.
Product Features
- Prestige Underbar Drainboard
- free-standing
- 36"W x 25"D x 36"H
- 7"H backsplash
- 18 gauge perforated removable drainboard top
- 1"IPS drain
- 20 gauge stainless steel construction
- 18 gauge stainless steel legs with adjustable stainless steel cross-bracing & adjustable stainless steel bullet feet
- NSF
Technical Specifications
| Manufacturer | Advance Tabco |
|---|---|
| Model Number | PRD-24-36 |
| Shipping Weight (Supplier Reference) | 73 lbs |
| Width | 36 in. |
| Depth | 25 in. |
| Height | 36 in. |
| Drainboard & Filler Board Type | drainboards |
| Type | free standing |
| Working Height | 29" |
| Base Type | open base |
| Construction | stainless steel construction |
| Width (side - side) OA | 31" - 36" |
| Depth (front - back) OA | 24" - 27" |
| Splash | 7" |
| Certifications | NSF |
Installation and Configuration
Check the manufacturer specification sheet for installation requirements, dimensions and connections. Optional accessories are sold separately unless identified as included in the product features.
Documents and Resources
Available documents: Spec Sheet. Open the product documents section to view or download the manufacturer PDFs.
