Description
American Range AR-48G-4B-CL-SBR 72” Professional Heavy Duty Restaurant Range
General Info and Features
- Culinary Series Heavy Duty Restaurant Range
- Gas
- (4) 32,000 BTU open burners
- (1) 48" griddle
- 5/8" thick plate
- Manual controls
- (1) convection oven with (1) rack on left
- (1) storage base on right
- Stainless steel front
- Sides & high shelf
- 6" chrome plated legs
- cETLus, ETL-Sanitation
- Made in USA
American Range AR-48G-4B-CL-SBR Standard Features
- Two piece lift off, easy to clean burners
- Five burners rated at 32,000 BTU/hr. each
- Heavy duty continuous cast iron top grates
- Bright red and black, phenolic, hard chrome skirted combination premium control knobs
- Removable, full width spill tray
- Stainless Steel island back trim
- One adjustable pilot for each burner for instant ignition
- Limited one year parts and labor warranty
American Range AR-48G-4B-CL-SBR Specifications
- Total BTU : 238,000
- KW : 70
- Shipping Weight Lbs.(Kg): 825 (375)
- Other Details : See spec. sheet
Technical specifications
Specifications
| Manufacturer | American Range |
|---|---|
| Model Number | AR-48G-4B-CL-SBR |
| Weight | 825 lbs |
| Width | 72 |
| Depth | 32.25 |
| Height | 56 |
| Installation Type | free standing |
| Range Type | standard duty/restaurant range |
| Number of Burners | 4 burners |
| Base Type | oven & storage base |
| Oven Type | convection oven |
| Number Of Ovens | 1 |
| Control Type | manual control |
| Top Configuration | burner & griddle |
| Plate Thickness | .625" = 5/8" |
| Exterior Finish | stainless steel front & sides |
| Top | (4) open burners, (1) 48" griddle |
| Vent | backriser with hi-shelf |
| Certifications | cETLus, ETL-Sanitation, Made in USA |
| Total BTU | 238,000 |
| Burner BTU | 32,000 |
| Oven BTU | 30,000 |
| Griddle/Charbroiler BTU | 20,000 |
Technical specifications
Specifications
| Manufacturer | American Range |
|---|---|
| Model Number | AR-48G-4B-CL-SBR |
| Weight | 825 lbs |
| Width | 72 |
| Depth | 32.25 |
| Height | 56 |
| Installation Type | free standing |
| Range Type | standard duty/restaurant range |
| Number of Burners | 4 burners |
| Base Type | oven & storage base |
| Oven Type | convection oven |
| Number Of Ovens | 1 |
| Control Type | manual control |
| Top Configuration | burner & griddle |
| Plate Thickness | .625" = 5/8" |
| Exterior Finish | stainless steel front & sides |
| Top | (4) open burners, (1) 48" griddle |
| Vent | backriser with hi-shelf |
| Certifications | cETLus, ETL-Sanitation, Made in USA |
| Total BTU | 238,000 |
| Burner BTU | 32,000 |
| Oven BTU | 30,000 |
| Griddle/Charbroiler BTU | 20,000 |
