Description
High‑Performance Cooking for Busy Restaurants
The AR-48G-DSB delivers high‑output cooking power and durable stainless steel construction for fast, reliable service in busy restaurants.
Key Features
- 48‑inch width with a 0.625" (5/8") thick steel griddle plate rated at 80,000 BTU (24 kW) for even high‑heat searing.
- Manual control valves on each 20,000 BTU/12" griddle burner and 32,000 BTU open burners provide precise temperature management.
- Stainless‑steel front, sides, backriser and optional 6" stub back offer corrosion‑resistant durability and easy cleaning.
- Standard cabinet/storage base includes a 20" back riser, high shelf and options for convection, innovection or storage configurations.
Technical specifications
Specifications
| Manufacturer | American Range |
|---|---|
| Model Number | AR-48G-DSB |
| Weight | 520 lbs |
| Width | 48 |
| Depth | 32.25 |
| Height | 56 |
| Range Type | standard duty/restaurant range |
| Base Type | cabinet/storage base |
| Plate Thickness | .625" = 5/8" |
| Exterior Finish | stainless steel front & sides |
| Top | (1) griddle |
| Vent | backriser with hi-shelf |
| Certifications | cETLus, ETL-Sanitation, Made in USA |
