Description
A self-contained ice machine and bin that makes up to 312 lb of cube ice a day under a counter or on its own.
The Dukers DIM-300 is a 30" wide cube ice machine with a built-in 88 lb bin for restaurants, bars, coffee shops, hotels and convenience stores. It makes up to 312 lb of ice per 24 hours, plugs into a standard 115V outlet and runs on R290 refrigerant. It needs a potable water line and a floor drain.
Will it fit · Will it plug in
- Outside size
- 30" W × 25.6" D × 38.7" H, including 6" legs (cabinet 32.7" tall)
- Power
- 115V / 60 Hz, 3 A, 680 W; NEMA 5-15P plug; 10 A fuse rating
- Water
- Potable water line, 138-550 kPa (about 20-80 psi), 38-90°F water; 1.5 m inlet hose included
- Drain
- Gravity drain to a floor drain with at least a 5 cm (2") air gap; 1.5 m drain hose included
- Room
- Rated for 35-110°F ambient air; keep the front ventilation window clear
- Crated size
- 32.28" W × 29.53" D × 39.37" H; 154.3 lb shipping weight (127.9 lb net)
Measure doorways and the spot under the counter before ordering: the unit needs 38.7" of height on its legs. Don't put anything on top of it or in front of the ventilation window.
312 lb a day
Rated at 312 lb per 24 hours at 70°F air and 50°F water, and 278 lb at 90°F air and 70°F water, so plan for the hotter number in a warm kitchen.
Bin built in
The 88 lb storage bin sits under the door, so the DIM-300 works as a complete ice station without a separate bin.
Standard outlet
It draws 3 A at 115V and comes with a NEMA 5-15P plug.
Easy cleaning
Removable air filter, water trough and distribution tube; a cleaning cycle takes about 35 minutes. Dukers says to clean the air filter at least twice a month.
Delivery and setup
- Free shipping on this item. See our shipping policy for delivery details.
- Usually ships in 1 business day.
- Covered by our Best Price Guarantee: call (201) 467-8222 if you find a lower price.
- Ships by freight in a crate of 32.28" × 29.53" × 39.37"; shipping weight 154.3 lb.
- Comes with a water inlet hose, a drain hose, 4 feet, an ice scoop and the manual (per the Dukers manual).
- Let it stand for 2 hours before starting it, as the Dukers manual instructs. A plumber may be needed for the water and drain lines.
- Inspect the shipment before signing for it and note any damage on the delivery receipt.
Questions buyers ask
How much ice does it make?
Up to 312 lb per 24 hours at 70°F air and 50°F water. In a hot room (90°F air, 70°F water) Dukers rates it at 278 lb. The bin holds 88 lb at a time.
What does it need to hook up?
A standard grounded 115V outlet (NEMA 5-15; 3 A, 680 W), a potable cold water line at 138-550 kPa (about 20-80 psi), and a floor drain below the unit, since it drains by gravity. Dukers recommends a water filter or softener where scale is a problem.
What size are the cubes?
7/8" × 7/8" × 7/8" cubes of about 11 g each.
Will it fit under my counter?
It is 30" wide, 25.6" deep and 38.7" tall on its 6" legs. Check the counter height and leave the front ventilation window clear.
How do I clean it?
Pour the cleaning solution into the water trough and run the cleaning cycle, about 35 minutes. Clean the removable air filter at least twice a month and the condenser regularly.
What does the warranty cover?
Dukers' DIM-150/300 spec sheet shows a 2-year parts and labor and 5-year compressor warranty. The ice machine manual says coverage starts on the installation date, excludes routine cleaning and damage from improper installation, and repairs must go through an authorized Dukers service provider.
When will it ship, and do you match lower prices?
It usually ships in 1 business day, shipping is free on this item, and it is covered by our Best Price Guarantee. Call (201) 467-8222 if you find a lower price.
Specs
| Manufacturer | Dukers |
|---|---|
| Model Number | DIM-300 |
| Quantity | 1 Each |
| Product Type | Self-Contained Cube Ice Machine with Bin |
| Width | 30 Inches |
| Depth | 25.6 Inches |
| Height | 38.7 Inches (with 6 Inch legs) |
| Cabinet Height | 32.7 Inches |
| Packaging Dimensions | 32.28 x 29.53 x 39.37 Inches (W x D x H) |
| Net Weight | 127.9 lbs |
| Shipping Weight | 154.3 lbs |
| Voltage | 115 Volts |
| Hertz | 60 Hz |
| Amps | 3 Amps |
| Wattage | 680 Watts |
| Fuse Rating | 10 Amps |
| Plug Type | NEMA 5-15P |
| Ice Production (70°F Air / 50°F Water) | 312 lbs per 24 Hours |
| Ice Production (90°F Air / 70°F Water) | 278 lbs per 24 Hours |
| Bin Storage Capacity | 88 lbs |
| Ice Type | Cube7/8 x 7/8 x 7/8 Inches, about 11 g |
| Condenser | Air-Cooled |
| Energy Use | 5.3 kWh per 100 lbs |
| Water Use | 53 L per 100 lbs |
| BTU | 3,000 BTU/H Average3,800 BTU/H Peak |
| Refrigerant | R290 |
| Ambient Temperature Range | 35 - 110 Degrees F |
| Water Temperature Range | 38 - 90 Degrees F |
| Water Pressure | 138 - 550 kPa |
| Exterior | Stainless Steel |
| Interior | Plastic with Antimicrobial Liner |
| Legs | 4 Legs, 6 Inches |
| Included | Water Inlet HoseDrain HoseIce Scoop |
| Certifications | cETLusETL Sanitation |
| Warranty | 2 Years Parts & Labor5 Years Compressor |
| Usage | Commercial Indoor |
