Insinger ENSIGN 40-2 50" Single Tank Roll Top Type Dishwasher,43 Racks/Hour-High Temp no Booster

Insinger ENSIGN 40-2 Roll Top Type Dishwasher

Insinger ENSIGN 40-2 Standard Features

• Automatic counter type single tank dishwasher with pass-thru telescoping hood
• 0.75 gallons/rack
• Capacity is 43- 16" x 16" racks per hour or 720 dishes
• No venting required
• A timed wash and rinse cycle
• Fully automatic operation with power on/off button
• Cycle starts when door is closed
• Tank heat: electric immersion heater
• Thermometer for wash
• Thermometer for final rinse
• Vacuum breaker
• Manifold clean-out brush
• Automatic tank fill
• Low water protection
• Detergent connection provision
• Space saving compact design
• Fully automatic operation
• Side mounted control panel (NEMA 12)
• Simplified scrap screen design
• Standard frame drip proof motor
• Door safety switch
• SureFire® Start-Up and Check-Out Service

Insinger ENSIGN 40-2 Specifications

• CONSTRUCTION- Hood and tank constructed of 16 gauge type 304 S/S. Hood unit of all welded seamless construction. All internal castings are non-corrosive lead free nickel alloy or bronze.
• DOORS- Two opening operating doors. Operating doors have fingertip control, rotating on S/S bracket. Doors formed of 18 gauge S/S.
• PUMP- Centrifugal type “packless” pump with a brass petcock drain. Construction includes ceramic seal and a balanced cast impeller on a precision ground stainless steel shaft, extension or sleeve. All working parts mounted as an assembly and removable as a unit without disturbing pump housing. One 1/2 hp motor, standard horizontal C-face frame, drip proof, internally cooled with ball-bearing construction.
• CONTROLS- Side-mounted control cabinet, housing motor controls and overload protection, transformer, contactors and all dishwasher integral controls. All controls safe low voltage 24 VAC.
• SPRAY SYSTEM- Wash and rinse spray systems made of 18-8 type 304 S/S pipe.
• WASH- Power wash arm above with 14 high pressure action cleaning slots and 6 power wash arms below, each designed with 5 high pressure action cleansing slots. The slots are precision milled for water control producing a fan spray. Wash arms are removable without the use of tools.
• FINAL RINSE- 1 spray body above designed with 4 power rinse nozzles and 1 power rinse coil below designed with 6 nozzles
• DRAIN- Overflow assembly with skimmer is removable without use of tools for drain line inspection. Heater protected by low water level controls.
• Shipping Weight : 400 lbs
