Description
Stack two Turbofan E22M3 or E23M3 half-size convection ovens in the floor space of one.
The Moffat Turbofan DSK22/23 is the double stacking kit for the Turbofan E22M3 and E23M3 half-size manual convection ovens, for cafes, bakeries and restaurants short on floor space. It is a stainless steel base stand on four adjustable feet with an oven spacer frame and a bottom oven vent extension. Two ovens on the kit take a 24" wide space, 57.5" high with E22M3 ovens or 61.88" with E23M3 ovens.
Will it fit
- Stacked size
- 24" W; 57.5" H with two E22M3, 61.88" H with two E23M3
- Stacked depth
- 25.38" (E22M3) or 25.25" (E23M3)
- Oven heights
- Bottom oven 17.88" off the floor; top oven 38.63" (E22M3) or 40.88" (E23M3) (per drawing)
- Base footprint
- 22.38" W × 19.25" D at the legs (per drawing)
- Fits
- Two Turbofan E22M3 or two E23M3 ovens (sold separately)
- Clearances
- 1" rear, 1" each side; 12" from heat sources
- Shipping
- 23.25" W × 6.25" D × 33.13" H carton, 33 lb
This is the adjustable-feet version; casters cannot be added later (the caster version is DSK22/23C). Ovens are sold separately.
Two ovens, one footprint
Two half-size ovens stacked on a 24" wide base.
Stainless steel stand
Welded square-tube base frame and a stainless steel spacer frame.
Adjustable feet
Four adjustable feet let you level the stack.
Vent extension included
The kit includes a vent extension for the bottom oven.
Delivery and setup
- Free shipping on this item. Usually ships in 1 business day.
- Ships knocked down in one 33 lb carton for assembly on site. Inspect the carton before you sign for it.
- Ovens are not included and ship separately.
- See our shipping policy for delivery details.
Questions buyers ask
Which ovens does it fit?
Moffat lists it for the Turbofan E22M3 and E23M3 half-size manual convection ovens. It stacks two ovens of the same model: two E22M3 or two E23M3.
Are the ovens included?
No. This is the stacking kit only. Moffat's double-stack models (E22M3/2, E23M3/2) are two individual ovens plus this kit, assembled on site.
How tall is the stack?
Two E22M3 ovens on this kit stand 57.5" high; two E23M3 ovens stand 61.88" high. Both stacks are 24" wide, and the bottom oven sits 17.88" off the floor.
Can I add casters later?
No. Moffat says casters cannot be retrofitted in the field for this adjustable-feet kit. If you need a mobile stack, order the DSK22/23C caster kit instead.
What is in the kit?
A welded stainless steel base stand on 4 adjustable feet, a stainless steel oven spacer frame and a bottom oven vent extension. It ships knocked down in one 33 lb carton.
What power do the ovens need?
Each oven has its own cord. An E22M3 plugs into a 110-120V outlet (NEMA 5-15P, 12 A); an E23M3 needs 208V, 13 A or 220-240V, 12 A (NEMA 6-15P). Plan one outlet per oven.
How much clearance does the stack need?
The same as the ovens: 1" at the rear and on each side, and 12" from sources of heat.
Specs
| Manufacturer | Moffat |
|---|---|
| Brand | Turbofan |
| Model Number | DSK22/23 (Moffat spec sheets also call it DSK2223) |
| Quantity | 1 Kit |
| Shipping Weight | 33 lbs |
| Packed Dimensions | 23.25" W x 6.25" D x 33.13" H2.8 cu. ft. |
| Compatible Ovens | Two Turbofan E22M3 ovensTwo Turbofan E23M3 ovens |
| Stacked Width | 24 Inches |
| Stacked Depth | 25.38 Inches (E22M3)25.25 Inches (E23M3) |
| Stacked Height | 57.5 Inches with two E22M3 ovens61.88 Inches with two E23M3 ovens |
| Bottom Oven Height | 17.88 Inches from the floor (per drawing) |
| Top Oven Height | 38.63 Inches (E22M3)40.88 Inches (E23M3) from the floor (per drawing) |
| Base Footprint | 22.38" W x 19.25" D at the legs (per drawing) |
| Base Stand | Welded 1 1/2" and 1 1/4" square tube front and rear frames |
| Feet | 4 adjustable feet |
| Casters | Not included; cannot be retrofitted in the field (use DSK22/23C for casters) |
| Spacer | Stainless steel oven spacer frame |
| Vent | Bottom oven vent extension |
| Material | Stainless steel base stand and spacer frame |
| Assembly | Supplied knocked down (CKD) for assembly on site |
| Ovens Included | No |
| Stacked Weight | 192 lbs net with two E22M3 ovens218 lbs net with two E23M3 ovens |
| Oven Clearances | 1" rear1" left side1" right side12" from heat sources |
| Country of Origin | New Zealand |
