Description
Put your Turbofan half-size oven at working height and keep six sheet pans right underneath.
The Moffat Turbofan SK23 is the stainless steel stand for the Turbofan E22M3 and E23M3 half-size convection ovens, for cafes, delis and bakeries that want the oven off the counter. It is 24" wide, has 6 runners for half-size sheet pans and rolls on four 3" casters, with locks on the front two. The oven is not included.
Will it fit
- Stand size
- 24" W × 20.88" D × 34.63" H
- With oven on top
- 56.63" high with an E22M3 (per drawing); 58.5" with an E23M3 (per brochure)
- Fits
- Turbofan E22M3 and E23M3 half-size ovens (sold separately)
- Pan storage
- 6 runners for half-size 13" × 18" sheet pans
- Oven clearances
- 1" rear, 1" each side; 12" from heat sources
- Shipping
- 24.88" W × 6" D × 35.5" H carton, 40 lb
Measure your space with the oven on top: 56.63" high with an E22M3, 58.5" with an E23M3. The stand ships knocked down.
Built for E22 and E23
Top frame supports suit Turbofan E22 and E23 Series half-size ovens.
Pan storage below
Six runners hold half-size sheet pans right under the oven.
Stainless steel frame
Welded 1 1/2" and 1 1/4" square tube frames, all stainless steel.
Locking casters
Four 3" swivel casters; the front two lock wheel and swivel.
Delivery and setup
- Free shipping on this item. Usually ships in 1 business day.
- Ships knocked down in one 40 lb carton for assembly on site. Inspect the carton before you sign for it.
- The oven is not included and ships separately.
- See our shipping policy for delivery details.
Questions buyers ask
Which ovens does it fit?
Moffat makes the SK23 for its Turbofan E22 and E23 Series half-size ovens and lists the E22M3 and E23M3 for it. The top frame supports are shaped to suit those ovens.
Is the oven included?
No. This is the stand only. The oven is sold separately.
How many pans can I store under the oven?
The stand has 6 tray runners for half-size 13" x 18" sheet pans.
How tall is it with the oven on top?
The stand is 34.63" high on its casters. Moffat's drawing shows 56.63" overall with an E22M3 on top, and the Turbofan brochure lists 58.5" with an E23M3.
Does it lock in place?
Yes. It rolls on four 3" swivel casters, and the two front casters have both wheel and swivel locks.
Does it come assembled?
No. Moffat ships it knocked down in one 40 lb carton for assembly on site.
Specs
| Manufacturer | Moffat |
|---|---|
| Brand | Turbofan |
| Model Number | SK23 |
| Quantity | 1 Stand |
| Shipping Weight | 40 lbs |
| Packed Dimensions | 24.88" W x 6" D x 35.5" H3.2 cu. ft. |
| Width | 24 Inches |
| Depth | 20.88 Inches |
| Height | 34.63 Inches (floor to oven support, on casters) |
| Net Weight | 35 lbs |
| Compatible Ovens | Turbofan E22M3Turbofan E23M3(E22 and E23 Series) |
| Height with Oven | 56.63 Inches with an E22M3 (per drawing)58.5 Inches with an E23M3 (per brochure) |
| Pan Capacity | 6 half-size 13" x 18" sheet pans |
| Tray Runners | 6 positions |
| Frame | Welded 1 1/2" and 1 1/4" square tube front and rear framesWelded rack supports and side frames |
| Casters | 4 x 3" swivel casters2 front casters with dual wheel and swivel lock |
| Material | All stainless steel |
| Assembly | Supplied knocked down (CKD) for assembly on site |
| Oven Included | No |
| Oven Clearances | 1" rear1" left side1" right side12" from heat sources |
| Certifications | NSF-4 |
| Country of Origin | New Zealand |
