Pegasus CG-24E Electric Clamshell Griddle, Nonstick Upper Plate, Separate Upper and Lower Thermostats, 6 kW, 208V 3-Phase

PegasusSKU: CG-24E

Price:
Regular price$2,427.00

Quick Shipping

Usually ships in 2–5 business days

Product Overview

  • Steel upper and lower plates; the upper plate has a nonstick Teflon film coating
  • Separate thermostatic controls for the upper and lower plates
  • Upper plate up to 482°F (250°C), lower plate up to 572°F (300°C)
  • Works as a flat griddle with the upper plate turned off
  • 6 kW at 208V 3-phase (3N/PE), 60 Hz
  • 31.29" L x 15.74" D x 19.29" H; 149.91 lb

Resources & Documents

Specs

Manufacturer Pegasus
Model Number CG-24E
Weight 149.91 lbs (Pegasus spec sheet)
Length 31.29 Inches
Depth 15.74 Inches
Height 19.29 Inches
Plates Steel lower plateSteel upper plate with Teflon film nonstick coating
Controls Separate thermostatic controls for upper and lower plates
Maximum Temperature Upper plate 482 Degrees F (250°C)Lower plate 572 Degrees F (300°C)
Power Type Electric
Wattage 6 kW
Voltage 208 Volts
Phase 3 Phase (3N/PE)
Hertz 60 Hz
Usage Commercial

Description

Press sandwiches, paninis and burgers from both sides, or open it up and use the lower plate as a griddle.

Pegasus CG-24E electric clamshell griddle

The Pegasus CG-24E is an electric clamshell griddle for cafes, delis, sandwich shops and food trucks with 208V 3-phase power. Steel plates cook from top and bottom, the upper plate has a nonstick Teflon film coating, and each plate has its own thermostat: up to 482°F on top and 572°F below. Turn the upper plate off and it works as a flat griddle.

Will it fit · Will it plug in

Outside size
31.29" L × 15.74" D × 19.29" H (as Pegasus lists length and depth)
Power
208V 3-phase with neutral (3N/PE), 60 Hz, 6 kW
Weight
149.91 lb (Pegasus spec sheet)

The spec sheet lists no amperage, cord, plug or wall clearances, so call us to confirm the circuit and placement before ordering. Leave room above the unit for the upper plate to open; the sheet gives no open height.

Cooks both sides

Steel upper and lower plates sear food from top and bottom at once.

Nonstick upper plate

A Teflon film coating on the upper plate helps food release.

Two thermostats

Set the upper plate up to 482°F (250°C) and the lower plate up to 572°F (300°C) separately.

Griddle mode

With the upper plate turned off, the lower plate works as a flat griddle.

Delivery and setup

  • Ships by freight carrier. Inspect it for damage before you sign for it.
  • Have a licensed electrician connect it to a 208V 3-phase circuit.
  • See our shipping policy for delivery options, including pickup at our Kearny, NJ warehouse.

Questions buyers ask

Can I use it as a regular griddle?

Yes. Pegasus says it can be operated as a grill with the upper plate turned off.

How hot does it get?

The upper plate goes up to 482°F (250°C) and the lower plate up to 572°F (300°C), each with its own thermostat.

What power does it need?

208V 3-phase with neutral (3N/PE), 60 Hz, 6 kW. The sheet does not list amps or a plug; call us to confirm the circuit before ordering.

Is the cooking surface nonstick?

The upper plate has a Teflon film nonstick coating. The lower plate is steel.

What warranty does it have?

The spec sheet does not state warranty terms. Call us for the current Pegasus warranty before ordering.

208V 3-Phase, 6 kW3N/PE, 60 Hz.
Two ThermostatsUpper and lower plates.
Nonstick Upper PlateTeflon film coating.
Up to 572°FLower plate maximum.

Specs

Manufacturer Pegasus
Model Number CG-24E
Weight 149.91 lbs (Pegasus spec sheet)
Length 31.29 Inches
Depth 15.74 Inches
Height 19.29 Inches
Plates Steel lower plateSteel upper plate with Teflon film nonstick coating
Controls Separate thermostatic controls for upper and lower plates
Maximum Temperature Upper plate 482 Degrees F (250°C)Lower plate 572 Degrees F (300°C)
Power Type Electric
Wattage 6 kW
Voltage 208 Volts
Phase 3 Phase (3N/PE)
Hertz 60 Hz
Usage Commercial
