Pegasus GR-36E 36" Electric Countertop Griddle, 3/4" Steel Plate, Thermostatic Controls, 12 kW, 208V 3-Phase or 1-Phase

PegasusSKU: GR-36E

Price:
Regular price$2,482.00

Quick Shipping

Usually ships in 2–5 business days

Product Overview

  • 36" wide x 24" deep cooking surface on a 3/4" thick polished steel plate
  • 3 heating zones, one thermostat per 12" section, 150 - 500°F
  • 12 kW at 208V: 3-phase 33.5 A per line, or 58 A on 1-phase (field convertible)
  • 3.25" front grease trough and 5" W x 20" D grease pan
  • Stainless steel body on heavy-duty 4" adjustable legs
  • cETLus and ETL Sanitation listed
  • One-year limited parts and labor warranty (USA and Canada)

Resources & Documents

Specs

Manufacturer Pegasus
Model Number GR-36E
Shipping Weight 270 lbs
Width 36 Inches
Depth 34.85 Inches
Height 17.24 Inches
Shipping Dimensions 48.81" W x 19.68" H x 37.79" D
Cooking Surface 36" W x 24" D
Griddle Plate 3/4" thick polished steel
Heating Zones 3 (one thermostat per 12" section)
Temperature Range 150 - 500 Degrees F
Controls Thermostatic
Power Type Electric
Wattage 12 kW
Voltage 208 Volts
Phase 3 Phase, field convertible to 1 Phase
Amps 33.5 A (208V 3-phase, per line)58 A (208V 1-phase)
Hertz 60 Hz
Grease Management 3.25" wide front grease trough5" W x 20" D grease pan
Construction Stainless steel body
Legs Heavy-duty 4" adjustable legs
Clearance, Non-Combustible Left 0"Right 0"Back 0"
Clearance, Combustible Left 6"Right 6"Back 6"
Certifications cETLusETL SanitationCE
Warranty One-year limited parts and labor (USA and Canada only)
Usage Commercial

Certifications

cETLus | ETL Sanitation | CE

Description

Cook eggs, pancakes, burgers and cheesesteaks on 36" of thick steel without a gas line.

Pegasus GR-36E electric griddle, front angle view

The Pegasus GR-36E is a 36" electric countertop griddle for diners, breakfast spots, burger joints and kitchens without gas. Its 3/4" thick polished steel plate is 24" deep and holds heat between batches, and each 12" section has its own thermostat (3 zones, 150 to 500°F). It runs on 12 kW at 208V, 3-phase or 1-phase after a field conversion.

Will it fit · Will it plug in

Outside size
36" W × 34.85" D × 17.24" H
Crated size
48.81" W x 19.68" H x 37.79" D, 270 lb
Power
208V, 60 Hz, 12 kW: 3-phase 33.5 A per line, or 58 A on 1-phase
Clearances
Non-combustible walls: 0" on the sides and back. Combustible walls: 6" on the sides and back

The spec sheet lists no cord or plug, so plan for an electrician to connect it to a 208V circuit sized for the phase you use. Place it on a sturdy, level counter or equipment stand; your local code may require a ventilation hood.

Thick steel plate

A 3/4" polished steel plate spreads heat evenly and recovers quickly after you load it.

3 cooking zones

Each 12" section has its own thermostat, so you can run different temperatures side by side.

Grease handling

A 3.25" front grease trough drains into a removable 5" W x 20" D grease pan.

Field convertible

Ships for 208V 3-phase and can be converted to 1-phase in the field.

Delivery and setup

  • Ships by freight carrier at 270 lb. Inspect it for damage before you sign for it.
  • Have a licensed electrician connect it to 208V power, 3-phase or 1-phase.
  • See our shipping policy for delivery options, including pickup at our Kearny, NJ warehouse.

Questions buyers ask

What power does it need?

208V, 60 Hz, 12 kW. On 3-phase it draws 33.5 A per line; on 1-phase it draws 58 A. It is field convertible from 3-phase to 1-phase.

Can I set different temperatures?

Yes. Each 12" section has its own thermostat, 3 in total, each adjustable from 150 to 500°F.

How thick is the plate?

The cooking plate is 3/4" thick polished steel, 24" deep.

How do I deal with grease?

Grease runs into a 3.25" front trough and a 5" W x 20" D grease pan that you empty and clean.

How close can it go to a wall?

Against non-combustible walls it needs 0" on the sides and back. Against combustible walls it needs 6" on the sides and back.

What does the warranty cover?

Pegasus gives a one-year limited parts and labor warranty in the USA and Canada.

cETLus & ETL SanitationListed for commercial food service.
208V, 12 kW3-phase or 1-phase, field convertible.
3/4" Steel Plate3 thermostatic zones.
1-Year WarrantyParts and labor, USA and Canada.

Specs

Manufacturer Pegasus
Model Number GR-36E
Shipping Weight 270 lbs
Width 36 Inches
Depth 34.85 Inches
Height 17.24 Inches
Shipping Dimensions 48.81" W x 19.68" H x 37.79" D
Cooking Surface 36" W x 24" D
Griddle Plate 3/4" thick polished steel
Heating Zones 3 (one thermostat per 12" section)
Temperature Range 150 - 500 Degrees F
Controls Thermostatic
Power Type Electric
Wattage 12 kW
Voltage 208 Volts
Phase 3 Phase, field convertible to 1 Phase
Amps 33.5 A (208V 3-phase, per line)58 A (208V 1-phase)
Hertz 60 Hz
Grease Management 3.25" wide front grease trough5" W x 20" D grease pan
Construction Stainless steel body
Legs Heavy-duty 4" adjustable legs
Clearance, Non-Combustible Left 0"Right 0"Back 0"
Clearance, Combustible Left 6"Right 6"Back 6"
Certifications cETLusETL SanitationCE
Warranty One-year limited parts and labor (USA and Canada only)
Usage Commercial

Certifications

cETLus | ETL Sanitation | CE
