Description
Cook eggs, pancakes, burgers and cheesesteaks on 48" of thick steel without a gas line.
The Pegasus GR-48E is a 48" electric countertop griddle for diners, breakfast spots, burger joints and kitchens without gas. Its 3/4" thick polished steel plate is 24" deep and holds heat between batches, and each 12" section has its own thermostat (4 zones, 150 to 500°F). It runs on 16 kW at 208V, 3-phase or 1-phase after a field conversion.
Will it fit · Will it plug in
- Outside size
- 48" W × 34.85" D × 17.24" H
- Crated size
- 48.81" W x 19.68" H x 37.79" D, 352 lb
- Power
- 208V, 60 Hz, 16 kW: 3-phase 50 / 50 / 33.5 A per line, or 77 A on 1-phase
- Clearances
- Non-combustible walls: 0" on the sides and back. Combustible walls: 6" on the sides and back
The spec sheet lists no cord or plug, so plan for an electrician to connect it to a 208V circuit sized for the phase you use. Place it on a sturdy, level counter or equipment stand; your local code may require a ventilation hood.
Thick steel plate
A 3/4" polished steel plate spreads heat evenly and recovers quickly after you load it.
4 cooking zones
Each 12" section has its own thermostat, so you can run different temperatures side by side.
Grease handling
A 3.25" front grease trough drains into a removable 5" W x 20" D grease pan.
Field convertible
Ships for 208V 3-phase and can be converted to 1-phase in the field.
Delivery and setup
- Ships by freight carrier at 352 lb. Inspect it for damage before you sign for it.
- Have a licensed electrician connect it to 208V power, 3-phase or 1-phase.
- See our shipping policy for delivery options, including pickup at our Kearny, NJ warehouse.
Questions buyers ask
What power does it need?
208V, 60 Hz, 16 kW. On 3-phase it draws 50 / 50 / 33.5 A per line; on 1-phase it draws 77 A. It is field convertible from 3-phase to 1-phase.
Can I set different temperatures?
Yes. Each 12" section has its own thermostat, 4 in total, each adjustable from 150 to 500°F.
How thick is the plate?
The cooking plate is 3/4" thick polished steel, 24" deep.
How do I deal with grease?
Grease runs into a 3.25" front trough and a 5" W x 20" D grease pan that you empty and clean.
How close can it go to a wall?
Against non-combustible walls it needs 0" on the sides and back. Against combustible walls it needs 6" on the sides and back.
What does the warranty cover?
Pegasus gives a one-year limited parts and labor warranty in the USA and Canada.
Specs
| Manufacturer | Pegasus |
|---|---|
| Model Number | GR-48E |
| Shipping Weight | 352 lbs |
| Width | 48 Inches |
| Depth | 34.85 Inches |
| Height | 17.24 Inches |
| Shipping Dimensions | 48.81" W x 19.68" H x 37.79" D |
| Cooking Surface | 48" W x 24" D |
| Griddle Plate | 3/4" thick polished steel |
| Heating Zones | 4 (one thermostat per 12" section) |
| Temperature Range | 150 - 500 Degrees F |
| Controls | Thermostatic |
| Power Type | Electric |
| Wattage | 16 kW |
| Voltage | 208 Volts |
| Phase | 3 Phase, field convertible to 1 Phase |
| Amps | 50 / 50 / 33.5 A (208V 3-phase, per line)77 A (208V 1-phase) |
| Hertz | 60 Hz |
| Grease Management | 3.25" wide front grease trough5" W x 20" D grease pan |
| Construction | Stainless steel body |
| Legs | Heavy-duty 4" adjustable legs |
| Clearance, Non-Combustible | Left 0"Right 0"Back 0" |
| Clearance, Combustible | Left 6"Right 6"Back 6" |
| Certifications | cETLusETL SanitationCE |
| Warranty | One-year limited parts and labor (USA and Canada only) |
| Usage | Commercial |
