Description
Four wok and pot burners on two levels, with the rear row raised 4", for Asian kitchens that cook in woks and stock pots side by side.
The ORSU-424 is the 24" model in Royal's Delux Original Flex System step-up line: 4 cast iron burners at 30,000 BTU, each under a 3/8" plate with a 9-3/4" stainless steel wok ring or a 12" x 12" cast iron grate, mixed the way you need, with the rear row raised 4". The fully welded frame is listed with a lifetime warranty on Royal's sheet. It suits Chinese, Thai and other Asian restaurants that hold woks and stock pots on one countertop. Order it for natural gas or propane; the pressure regulator comes with the unit.
Will it fit · Will it plug in
- Outside size
- 24" W × 31-1/2" D (spec table; the drawing shows 30-1/4"); 10" high at the front, 14" at the raised rear section, on 4" adjustable legs
- Counter space
- Countertop unit; set it on a level counter or a Royal equipment stand
- Clearances
- Combustible walls: 4" rear, 15" sides. Non-combustible walls: 0" (spec sheet)
- Gas
- Natural gas or LP, 120,000 BTU/hr total (4 × 30,000); 3/4" NPT inlet at the right rear
- Gas pressure
- 5" W.C. natural gas, 10" W.C. propane; regulator supplied
- Electrical
- None listed: standing pilots and manual valves
- Shipping
- 144 lbs. on the spec sheet (154 lbs. in the 2026 catalog); crated 34" D × 15" H × 26-1/2" W (Royal's catalog: 34" D × 15" H × width + 2-1/2")
Leave room behind the unit for the gas line and regulator, and check that every burner sits under your hood.
Wok ring or grate
Each 12" section takes a heavy 3/8" thick plate with a 9-3/4" stainless steel wok ring or a heavy cast iron 12" x 12" bowl-design grate; Royal lets you mix and match.
4 burners at 30,000 BTU
Cast iron burners with removable, non-clog lift-off heads and flat top design, each with a protected standing pilot and its own manual control.
Raised rear burners
The rear row sits 4" higher than the front, and stainless steel ends are standard on the step-up model.
Fully welded frame
The Delux frame is fully welded; Royal's spec sheet lists it with a lifetime warranty.
Easy to clean
A full-width removable stainless steel crumb pan slides out, and the stainless sides, valve cover and front ledge wipe clean.
Delivery and setup
- Ships by freight carrier; the shipping cost depends on your location. See our shipping policy for details.
- Call (201) 467-8222 for the current lead time before you schedule installation.
- Choose natural gas or LP when you order. If your kitchen is above 2,000 feet, tell us the elevation so Royal can set the unit up for it.
- A qualified gas installer must connect the supplied regulator and a manual shut-off valve ahead of the unit, following local codes.
- Inspect the shipment before signing and note any visible damage on the freight bill.
Questions buyers ask
Does it run on natural gas or propane?
Either. Pick Natural Gas or Liquid Propane (LP) before adding it to the cart; Royal builds it for the gas you specify. Tell us your elevation if you are above 2,000 feet.
Does it come with wok rings or grates?
Each section can have a 3/8" plate with a 9-3/4" stainless steel wok ring or a 12" x 12" cast iron grate. Royal's catalog lists extra grates, extra wok ring tops and swapping a grate for a wok ring as options, so tell us the mix you want when you order.
What gas connection does it need?
A 3/4" NPT connection at the right rear of the unit. Pressure is 5" W.C. for natural gas and 10" W.C. for propane, and the regulator ships with the unit for your installer to connect.
How much clearance does it need from the wall?
Royal's spec sheet lists 4" at the rear and 15" at the sides from combustible walls, and 0" from non-combustible walls.
How much higher are the rear burners?
The rear row is raised 4": Royal's drawing shows 10" at the front and 14" at the rear section.
What does it weigh?
Royal's 1-26 spec sheet lists 144 lbs. shipping weight and the 2026 catalog lists 154 lbs. Plan for 154 lbs. when you arrange the delivery.
What does the warranty cover?
Royal's limited warranty is 2 years on parts and 1 year on labor from installation (up to 30 months from manufacture); the spec sheet also lists a lifetime warranty on the welded frame. Cast iron parts, such as grates and burner heads, are covered for 90 days. Labor is covered when an authorized Royal service agency does the work.
How do I clean it?
Daily, clean the grates and wok rings with warm water, a mild cleaner and a wire brush, brush debris from around the burners and empty the crumb pan. Now and then remove the burners, clean them with a wire brush and check that the ports are open.
Specs
| Manufacturer | Royal Range of California |
|---|---|
| Model Number | ORSU-424 |
| Series | Delux Original Flex System Step-Up |
| Quantity | 1 Each |
| Shipping Weight | 144 lbs. (spec sheet)154 lbs. (2026 catalog) |
| Width | 24 Inches |
| Depth | 31.5 Inches (spec table)30-1/4" on the drawing |
| Height | 10 Inches front14 Inches rear section (Royal drawing) |
| Legs | 4" high adjustable heavy duty legs |
| Crated Size | 34" D x 15" H x 26-1/2" W |
| Installation | Countertop |
| Gas Type | Natural Gas or Liquid Propane (specify when ordering) |
| Number of Burners | 4 (rear row raised 4") |
| BTU per Burner | 30,000 BTU/H |
| Total BTU | 120,000 BTU/H (4 x 30,000) |
| Burners | Cast iron, removable non-clog lift-off heads, flat top design |
| Tops | 3/8" thick plate with 9-3/4" stainless steel wok ring or heavy cast iron 12" x 12" bowl-design grate, mix and match |
| Ignition | Protected standing pilots, stainless steel pilot tubing |
| Controls | Manual control for each burner |
| Gas Inlet | 3/4" NPT, right rear |
| Gas Pressure | 5" W.C. Natural Gas10" W.C. Propane |
| Pressure Regulator | Supplied, connected by the installer |
| Clearance (Combustible) | 4" rear15" sides |
| Clearance (Non-Combustible) | 0" rear0" sides |
| Construction | Fully welded frameStainless steel sides, front valve cover and ledgeDouble wall side panelsFull-width removable stainless steel crumb panStainless steel ends |
| Options | Extra top gratesExtra wok ring topSubstitute top grate for wok ring top |
| Certifications | CSA C/USCSA Sanitation |
| Warranty | 2 years parts, 1 year laborWelded frame lifetime (per spec sheet)Cast iron parts 90 days |
| Usage | Commercial use only |
