Description
A 12" heavy duty manual griddle that adds a flat top to a short line or a crowded counter.
The RMG-12 is the narrowest of Royal's heavy duty manual griddles: one 30,000 BTU stainless steel U-shaped burner under a 3/4" thick polished steel plate with a full 24" cooking depth. It suits cafes, food counters and kitchens that need a dedicated spot for eggs, pancakes or sandwiches. It lights with a standing pilot and runs on a manual valve, so it needs a gas line but no electrical outlet.
Will it fit · Will it plug in
- Outside size
- 12" W × 32-1/2" D
- Height
- 11" from the counter to the cooking surface on 4" adjustable legs, plus a rear and side splash (drawing)
- Cooking surface
- 24" deep, 3/4" thick steel plate
- Clearances
- Spec sheet, combustible walls: 4" rear, 15" sides. Royal's owner's manual lists 6" rear, 4" sides for manual griddles. Non-combustible walls: 0"
- Gas
- Natural gas or LP, 30,000 BTU/hr; 3/4" NPT inlet at the right rear, 5" above the counter
- Gas pressure
- 5" W.C. natural gas, 10" W.C. propane; regulator supplied
- Electrical
- None: standing pilot and manual valve
- Crated size
- 34" D × 15" H × 14-1/2" W (width + 2-1/2", Royal catalog)
- Shipping weight
- 140 lbs.
The two clearance tables differ; plan for the larger figures (6" rear, 15" sides) from combustible walls, or install against non-combustible construction.
One heavy duty burner
A stainless steel U-shaped burner rated at 30,000 BTU/hr heats the full 12" width, with its own manual control.
3/4" polished plate
A 3/4" thick steel griddle plate with a polished cooking surface and a 24" cooking depth. A 1" plate is available as an option.
Grease handling
A 4" wide stainless steel grease trough with a large drain opening empties into a 1-1/2 gallon stainless steel grease can.
Low-profile chassis
Compact heavy gauge chassis with stainless steel sides, front valve cover and ledge, double wall side panels and 4" adjustable heavy duty legs.
Delivery and setup
- Ships by freight carrier; the shipping cost depends on your location. See our shipping policy for details.
- Call (201) 467-8222 for the current lead time before you schedule installation.
- Choose natural gas or LP when you order. If your kitchen is above 2,000 feet, tell us the elevation so Royal can set the unit up for it.
- A qualified gas installer must connect the supplied regulator and a manual shut-off valve ahead of the unit, following local codes.
- Inspect the shipment before signing and note any visible damage on the freight bill.
Questions buyers ask
Does it run on natural gas or propane?
Either. Pick Natural Gas or Liquid Propane (LP) before adding it to the cart; Royal builds it for the gas you specify. Tell us your elevation if you are above 2,000 feet.
Does it need electricity?
No. It lights with a standing pilot and the burner runs on a manual valve, so no outlet is needed.
How is the temperature controlled?
By hand: one manual valve controls the burner. There is no thermostat; if you want a set temperature, look at Royal's thermostatic RTG griddles.
What gas connection does it need?
A 3/4" NPT connection at the right rear. Manifold pressure is 5" W.C. for natural gas and 10" W.C. for propane; the regulator ships with the unit for your installer to connect.
How much clearance does it need?
The spec sheet lists 4" rear and 15" sides from combustible walls; Royal's owner's manual lists 6" rear and 4" sides. Plan for the larger figures, or 0" from non-combustible walls.
Can I get a thicker plate or a grooved section?
Yes. Royal offers a 1" thick plate, a grooved griddle section and a chrome griddle plate, plus stainless steel equipment stands. Call us to order an option.
What does the warranty cover?
Royal's limited warranty is 2 years on parts and 1 year on labor from installation (up to 30 months from manufacture), with labor done by an authorized Royal service agency.
How do I clean the griddle plate?
Daily, scrub the warm plate with warm water and a fine-grit griddle brick, and empty and clean the grease can. Wipe stainless steel with hot soapy water; don't use steel wool or abrasive powders.
Specs
| Manufacturer | Royal Range of California |
|---|---|
| Model Number | RMG-12 |
| Quantity | 1 Each |
| Shipping Weight | 140 lbs. |
| Crated Dimensions | 34" D x 15" H x 14-1/2" W |
| Width | 12 Inches |
| Depth | 32-1/2 Inches |
| Height | 11" to the cooking surface on 4" legs (low profile) |
| Cooking Surface Depth | 24 Inches |
| Griddle Plate | 3/4" thick steel, polished cooking surface |
| Installation | Countertop |
| Gas Type | Natural Gas or Liquid Propane (specify when ordering) |
| Total BTU | 30,000 BTU/H |
| Burners | 1 stainless steel U-shaped burner, 30,000 BTU/H |
| Controls | Manual valve |
| Ignition | Standing pilot (stainless steel pilot tubing) |
| Gas Inlet | 3/4" NPT, right rear |
| Gas Pressure | 5" W.C. Natural Gas10" W.C. Propane |
| Pressure Regulator | Supplied, connected by the installer |
| Electrical | None required |
| Clearance (Combustible) | Spec sheet 4" rear, 15" sidesOwner's manual 6" rear, 4" sides |
| Clearance (Non-Combustible) | 0" rear0" sides |
| Grease Collection | 4" wide stainless steel grease trough1-1/2 gallon stainless steel grease can |
| Construction | Compact heavy gauge chassisStainless steel sides, front valve cover and ledgeDouble wall side panelsAeration panels4" adjustable heavy duty legs |
| Options | 1" thick griddle plateGrooved griddleChrome griddle plateStainless steel equipment stand5" swivel casters for stand |
| Certifications | CSA C/USCSA Sanitation |
| Warranty | 2 years parts, 1 year labor |
| Usage | Commercial use only |
