Description
A 36" stand-alone restaurant oven on 6" legs, for kitchens that need oven capacity without a range top.
The RR-36-LB is Royal's 36" wide restaurant-type gas oven with one standard oven, 35,000 BTU/hr in all, 29" high on 6" legs. It suits restaurants, bakeries and caterers that need range-style ovens under a hood or beside a cooking line. It needs no electrical connection: the oven lights with a push-button piezo igniter.
Will it fit · Will it plug in
- Outside size
- 36" W × 28.75" D × 29" H on 6" legs
- Clearances
- Combustible walls: 4" rear, 15" sides. Non-combustible walls: 0"
- Gas
- Natural gas or LP, 35,000 BTU/hr total; 3/4" NPT inlet at the right rear
- Gas pressure
- 5" W.C. natural gas, 10" W.C. propane; regulator supplied
- Electrical
- None listed: piezo push-button pilot ignition
- Shipping weight
- 185 lbs.
Measure doorways and the space under the hood first; Royal gives no crated size for these ovens.
Standard oven
A 35,000 BTU stainless steel "U" burner, an oven safety valve with 100% shut-down if the pilot goes out, and matchless piezo ignition for the standing pilot.
Built for daily use
A solidly welded heavy gauge frame with stainless steel front, sides, top and kick plate, and porcelain oven contact surfaces.
Fits beside the line
36" wide on 6" legs; add 5" swivel casters or seismic flanged feet as options.
Delivery and setup
- Ships by freight carrier; the shipping cost depends on your location. See our shipping policy for details.
- Call (201) 467-8222 for the current lead time before you schedule installation.
- Choose natural gas or LP when you order. If your kitchen is above 2,000 feet, tell us the elevation so Royal can set the unit up for it.
- A qualified installer must connect it following local codes, with the supplied pressure regulator and a manual shut-off valve ahead of the unit.
- Inspect the shipment before signing and note any visible damage on the freight bill.
Questions buyers ask
Does it run on natural gas or propane?
Either. Pick Natural Gas or Liquid Propane (LP) before adding it to the cart; Royal builds it for the gas you specify. Tell us your elevation if you are above 2,000 feet.
Does it need an electrical outlet?
No electrical connection is listed. The standing pilot lights with a push-button piezo igniter and the oven safety valve shuts the gas off if the pilot goes out.
How is the BTU total figured?
1 standard oven × 35,000 = 35,000 BTU/hr.
How much clearance does it need?
Royal lists 4" at the rear and 15" at the sides from combustible walls, and 0" from non-combustible walls.
How many racks come with it?
Each standard oven comes with 1 chrome rack on 5-position guides. Additional racks are an option.
What does the warranty cover?
Royal's limited warranty is 2 years on parts and 1 year on labor from installation (up to 30 months from manufacture), with labor by an authorized Royal service agency.
Specs
| Manufacturer | Royal Range of California |
|---|---|
| Model Number | RR-36-LB |
| Series | Royal Series |
| Quantity | 1 Each |
| Shipping Weight | 185 lbs. |
| Width | 36 Inches |
| Depth | 28.75 Inches |
| Height | 29 Inches |
| Legs | 6" |
| Decks | 1 |
| Gas Type | Natural Gas or Liquid Propane (specify when ordering) |
| Total BTU | 35,000 BTU/H |
| BTU Math | 1 standard oven × 35,000 = 35,000 BTU/hr |
| Standard Oven | Stainless steel "U" burner, 35,000 BTU/HOven safety valve, 100% shut-downPiezo push-button pilot ignition |
| Standard Oven Racks | 1 chrome rack, 5-position rack guides |
| Oven Interior | Porcelain contact surfaces |
| Gas Inlet | 3/4" NPT, right rear |
| Gas Pressure | 5" W.C. Natural Gas10" W.C. Propane |
| Pressure Regulator | Supplied, connected by the installer |
| Clearance (Combustible) | 4" rear15" sides |
| Clearance (Non-Combustible) | 0" rear0" sides |
| Construction | Solid welded heavy gauge metal frameStainless steel front, sides, top and kick plate |
| Options | Additional oven rack5" swivel casters (set of 4, 2 locking)Seismic flanged feet |
| Certifications | CSA C/USCSA Sanitation |
| Warranty | 2 years parts, 1 year labor |
| Usage | Commercial use only |
