Description
The Traulsen G21010 is a two-section reach-in refrigerator with two full-height hinged glass doors in a left-right configuration. Its top-mounted, self-contained refrigeration system keeps the cabinet footprint focused on refrigerated storage while the glass doors allow staff to view contents before opening the cabinet.
This model provides 46.90 cu. ft. of net capacity and comes with six epoxy-coated wire shelves—three per section. A microprocessor control with LED display, interior LED lighting, locking doors, and front-facing condenser access support day-to-day use in busy commercial kitchens.
Applications and Workflow
Suitable for refrigerated ingredient, beverage, packaged product, and prepared-item storage in restaurant kitchens, cafeterias, markets, and institutional foodservice operations. This is a reach-in refrigerator, not a freezer; its stated operating range is 34°F to 38°F.
Features and Practical Benefits
Full-height glass-door access
Two full-height glass doors provide a clear view of stored product. The G21010 specifically uses left-right door hinging, helping buyers plan aisle access and adjacent equipment placement.
Organized two-section storage
The cabinet has 46.90 cu. ft. of net capacity and includes six factory-installed epoxy-coated shelves, with three shelves in each section.
Top-mounted self-contained refrigeration
The refrigeration system is mounted above the cabinet and uses R-450A refrigerant. Its front-facing condenser is designed for accessible routine cleaning.
Controls and cabinet visibility
A water-resistant microprocessor control includes a three-digit LED display, while an exterior-mounted switch operates the interior LED lighting.
Door and mobility features
Locking, self-closing doors stay open at 120 degrees for loading. Four 6-inch high locking casters are included for positioning and cleaning access.
Technical Specifications
| Manufacturer model | G21010 |
|---|---|
| Cabinet configuration | Two-section reach-in refrigerator with full-height hinged glass doors |
| Door hinging | Left-right |
| Net capacity | 46.90 cu. ft. (1328 L) |
| Overall width | 52 1/8 in. (132.4 cm) |
| Overall depth | 35 1/2 in. (90.1 cm) |
| Overall height | 83 3/8 in. (211.9 cm) |
| Depth with door open 90 degrees | 56 3/4 in. (144 cm) |
| Clear full-door opening | 21 in. W x 57 1/2 in. H |
| Standard shelves | 6 |
| Electrical requirement | 115/60/1, NEMA 5-15P attached plug |
| Full-load amperage | 8.4 A |
| Refrigerant | R-450A |
| Refrigerant charge | 24 oz. (680.4 g) |
| Compressor horsepower | 5/8 HP |
| Required top clearance | 12 in. above |
| Standard operating temperature | 34°F to 38°F |
| Casters | Four 6 in. high locking casters |
Installation and Purchasing Considerations
- Plan a floor location for the 52 1/8 in. W x 35 1/2 in. D x 83 3/8 in. H cabinet; the stated height is on the supplied 6 in. casters.
- Allow for the doors at 90 degrees: overall depth becomes 56 3/4 in. Confirm this swing space will not obstruct aisles, prep stations, or nearby equipment.
- Provide 12 in. of clearance above the cabinet for the top-mounted refrigeration system.
- Connect to a 115/60/1 electrical supply. The unit has an attached NEMA 5-15P plug and a 9 ft. cord.
- Use the G21010's left-right door hinging when planning the opening direction. Other hinge arrangements are separate configurations.
- Keep the front-facing condenser accessible for cleaning and service.
Choosing This Configuration
G21010 is the full-height glass-door, left-right hinged version in this two-section G-Series family; it is not the half-height-door configuration.
This model is a self-contained refrigerator with a top-mounted refrigeration system, rather than a remote-condensing model.
Six epoxy-coated wire shelves are standard. Tray slides, additional shelves, and legs are listed as field-installed accessories or options and should be specified separately when needed.
Frequently Asked Questions
What is the door configuration on the Traulsen G21010?
It has two full-height hinged glass doors with left-right hinging. The doors are self-closing, lockable, and have a stay-open position at 120 degrees.
How much shelving is included?
Six epoxy-coated steel wire shelves are standard: three shelves per section. They are factory installed on shelf pins.
What electrical connection does this refrigerator use?
The G21010 operates on 115/60/1 power and has an attached NEMA 5-15P plug with a 9 ft. cord.
What clearance should be planned for installation?
Allow 12 in. above the cabinet. Also account for a 56 3/4 in. overall depth when a door is opened to 90 degrees.
