Description
The Traulsen RDH232WUT-FHS is a two-section dual-temperature reach-in cabinet that combines a heated left section with a refrigerated right section. This full-height solid-door configuration keeps the two environments in one 58-inch-wide footprint for operations that need chilled ingredients or prepared items close to hot holding space.
This self-contained R-Series cabinet has a stainless steel exterior and interior, Smart Control with LED display, and automatic interior LED lighting. It includes three coated wire shelves per section, for six shelves total, along with four adjustable 6-inch stainless steel legs and a factory-attached 9-foot cord with NEMA L14-20P plug.
Applications and Workflow
Suitable for commercial kitchens, cafeterias, healthcare foodservice, and institutional serving operations that need separate refrigerated and heated holding zones in one reach-in cabinet. The left compartment is heated and the right compartment is refrigerated; it is not a two-zone refrigerator or a two-zone heated cabinet.
Features and Practical Benefits
Separate hot and refrigerated zones
A heated left section and refrigerated right section support adjacent storage of products requiring different cabinet environments without using two separate reach-ins.
Full-height solid-door access
The RDH232WUT-FHS is the full-height solid-door version, providing tall, uninterrupted access to each cabinet section.
Built-in shelf storage
Six standard coated wire shelves are supplied—three per section—with 25.28 square feet of total listed shelf area.
Self-contained refrigeration
The refrigerated right side uses a top-mounted, self-contained R-450A refrigeration system, eliminating the need to connect this standard configuration to a remote condenser.
Serviceable reach-in layout
Self-closing doors stay open at 120 degrees, while the 90-degree open-door depth is published for planning aisle and access clearance.
Technical Specifications
| Manufacturer model | RDH232WUT-FHS |
|---|---|
| Cabinet configuration | Two-section dual-temperature reach-in; full-height solid doors |
| Section arrangement | Heated left section; refrigerated right section |
| Net capacity | 46.86 cu. ft. |
| Overall width | 58 in. |
| Overall depth | 35 in. |
| Overall height | 83 1/4 in. on 6 in. legs |
| Depth with door open 90° | 57 11/16 in. |
| Clear door width | 21 1/8 in. |
| Clear full-door height | 57 5/8 in. |
| Standard shelves | 6 total |
| Shelf arrangement | Three coated wire shelves per section |
| Total shelf area | 25.28 sq. ft. |
| Electrical configuration | 208-230/115/60/1; NEMA L14-20P |
| Wattage at 208V | 2000 W |
| Full-load amperage | 13.5 A |
| Power cord | 9 ft. cord with plug |
| Refrigerant | R-450A |
| Compressor horsepower | 1/3 HP |
| Refrigerated-section operating temperature | 34–38°F |
| Heated-section operating temperature | 140–180°F |
| Standard legs | Four 6 in. adjustable stainless steel legs |
Installation and Purchasing Considerations
- Allow a 58-inch-wide by 35-inch-deep equipment footprint; overall height is 83 1/4 inches on the included 6-inch adjustable legs.
- Plan for a 57 11/16-inch overall depth when a door is open to 90 degrees. Each full-height door has a 21 1/8-inch clear width and 57 5/8-inch clear height.
- Provide 12 inches of top clearance where possible for optimum performance and service access.
- Verify the electrical supply before purchase. The published electrical configuration is 208-230/115/60/1 with a NEMA L14-20P plug; the cabinet is supplied with a 9-foot cord.
- This is a self-contained model with the refrigeration system mounted at the top behind the louver assembly. Keep the front-facing condenser area accessible for cleaning and service.
- The cabinet is supplied on four adjustable 6-inch stainless steel legs. Casters and other support arrangements are listed as alternatives, not standard equipment.
Choosing This Configuration
RDH232WUT-FHS is the two-section, full-height solid-door configuration. The related RDH232WUT-HHS is identified as the half-height solid-door configuration.
This model has a heated left section and refrigerated right section. Confirm that this left/right workflow matches the planned installation location.
Standard interior equipment is three coated wire shelves per section. Tray slides, extra shelves, stainless shelves, glass doors, casters, and other listed accessories are not established as included with this exact cabinet.
Frequently Asked Questions
Which side is heated on the RDH232WUT-FHS?
The left section is heated, and the right section is refrigerated.
What temperatures are published for each section?
The refrigerated compartment is published at 34–38°F, and the heated compartment is published at 140–180°F.
Does this cabinet need a remote refrigeration system?
No. This model is specified with a top-mounted, self-contained refrigeration system on the right side.
What electrical connection does it use?
The published configuration is 208-230/115/60/1, and the cabinet is equipped with one NEMA L14-20P plug on a 9-foot cord.
