Description
The Traulsen RDT332WUT-FHS is a three-section, self-contained reach-in refrigerator/freezer with full-height solid doors. Its left and center sections provide refrigerated storage, while the right section is dedicated freezer space, allowing refrigerated and frozen inventory to be staged in one 86 1/8-inch-wide cabinet.
This R-Series configuration has a stainless steel exterior and interior, three adjustable coated-wire shelves per section, and a top-mounted balanced refrigeration system. Full-height doors provide tall vertical access, with standard left/right/right hinging across the three sections.
Applications and Workflow
Suitable for commercial kitchens, prep areas, and back-of-house storage where refrigerated ingredients and frozen inventory need separate compartments in one reach-in footprint. This model is a refrigerator/freezer combination: the left and center sections refrigerate, while only the right section freezes.
Features and Practical Benefits
Separate refrigerated and frozen zones
The cabinet places refrigerator storage in the left and center sections and freezer storage in the right section, keeping the two temperature zones physically separated.
Full-height solid-door access
Three full-height solid doors give each section a single tall opening. The standard hinge arrangement is left/right/right, and the doors self-close and stay open at 120 degrees.
Organized shelf storage
Nine coated wire shelves are standard—three per section—and are adjustable on shelf pins for configuring storage space around product heights.
Stainless steel cabinet surfaces
The exterior and interior are stainless steel, supporting a durable reach-in storage cabinet for commercial work areas.
Self-contained top-mounted refrigeration
The balanced, self-contained system is top mounted behind the louver assembly, with separate R-450A refrigerator and R-448A freezer refrigerants.
Technical Specifications
| Manufacturer model | RDT332WUT-FHS |
|---|---|
| Cabinet configuration | 3-section refrigerator/freezer reach-in; refrigerator left and center, freezer right |
| Door configuration | 3 full-height solid doors |
| Standard door hinging | Left/right/right |
| Exterior and interior material | Stainless steel |
| Overall width | 86 1/8 in. |
| Overall depth | 35 1/8 in. |
| Overall height on legs | 83 7/16 in. |
| Depth with door open 90 degrees | 56 11/16 in. |
| Clear full-door height | 57 9/16 in. |
| Net capacity | 75.38 cu. ft. |
| Refrigerator capacity | 50.52 cu. ft. |
| Freezer capacity | 24.86 cu. ft. |
| Standard shelves | 9 coated wire shelves |
| Electrical service | 115/60/1, hard wired |
| Full-load amperage | 25.3 A |
| Refrigerator refrigerant | R-450A |
| Freezer refrigerant | R-448A |
| Refrigerator compressor horsepower | 1/2 HP |
| Freezer compressor horsepower | 1/2 HP |
| Standard refrigerator temperature | 34 to 38°F |
| Standard freezer temperature | -5 to 0°F |
| Included legs | Four 6-inch adjustable stainless steel legs |
| Preferred top clearance | 12 in. |
Installation and Purchasing Considerations
- Plan a finished footprint of 86 1/8 inches wide by 35 1/8 inches deep by 83 7/16 inches high on the included 6-inch adjustable legs.
- Allow for a 56 11/16-inch overall depth when a door is opened 90 degrees. Full-door clear opening height is 57 9/16 inches.
- The unit is specified for 115/60/1 electrical service and is hard wired; verify the dedicated electrical connection at the installation location before purchase.
- Provide 12 inches of top clearance where possible for preferred performance and service access.
- Confirm that the 86 1/8-inch cabinet width, door swing, and 83 7/16-inch installed height fit the delivery path and final location.
Choosing This Configuration
This exact RDT332WUT-FHS configuration has three full-height solid doors. The similarly named HHS configuration uses half-height solid doors instead.
The freezer compartment is standard on the right; the left and center compartments are refrigerator sections.
Standard support is four 6-inch adjustable stainless steel legs. Casters and alternate bases are listed as options rather than standard equipment.
The standard shelf arrangement is nine coated wire shelves. Tray slides and stainless steel shelves are optional configurations.
Frequently Asked Questions
Which sections refrigerate and which section freezes?
The left and center sections are refrigerator compartments, and the right section is the freezer compartment.
Does this model have full-height or half-height doors?
RDT332WUT-FHS is the full-height solid-door version, with three full-height solid doors.
How many shelves are included?
It includes nine standard coated wire shelves, with three adjustable shelves installed in each section.
What electrical connection does it require?
The specification lists 115/60/1 electrical service and a hard-wired connection.
