True GDM-10PT-HC~TSL01 25" 1-Door Glass Swing Door Pass-Thru Merchandiser Refrigerator, 33-38°F, 3 Shelves, R290, 115V
A pass-thru glass door merchandiser that customers shop from the front while staff restock from the back.
The True GDM-10PT-HC~TSL01 is a 24-7/8" wide pass-thru glass door merchandiser refrigerator with 1 self-closing Low-E double-pane glass swing door. Its bottom-mounted R290 system holds 33°F to 38°F. Inside, 3 adjustable PVC-coated wire shelves hold the product, with LED interior lighting and a door sign decal. It plugs into a dedicated 115V, 15 amp outlet with the included NEMA 5-15P cord.
Measure every doorway and turn on the delivery path; the smallest outside dimension is the 24-7/8" cabinet width.
A factory-balanced, self-contained R290 system holds 33°F to 38°F.
Glass doors on the front and back let staff restock from behind while customers shop the front.
Natural R290 hydrocarbon refrigerant with zero ozone depletion potential. The bottom-mounted condenser coil is easy to reach for cleaning.
3 adjustable PVC-coated wire shelves, 20-5/8" x 17-1/2", adjust in 1/2" steps. The "no stoop" bottom shelf sits above the condensing unit.
Safety-shielded LED interior lighting spreads light evenly through the cabinet. The door carries a sign decal.
1 self-closing Low-E double-pane glass swing door with a torsion-type closure. Magnetic gaskets come off without tools for cleaning. Exterior: black powder-coated cold rolled steel.
A dedicated 115V, 15 amp outlet. The unit draws 2.2 A and comes with a 10 ft. cord and NEMA 5-15P plug.
The cabinet is 25-1/2" deep, 24-7/8" wide and 53-3/8" tall. Add 1-5/8" each side for door handles. Measure the doorway and every turn on the way in.
True rates the GDM-10PT-HC~TSL01 to hold 33°F to 38°F.
3 adjustable PVC-coated wire shelves, adjustable in 1/2" steps.
Yes. The condensing unit sits at the bottom of the cabinet, and True designed the condenser coil to be easy to reach for cleaning.
Yes. True products carry our Best Price Guarantee. Found it lower? Send us the lower price with a quote request or call us, and we will match it.
Specs
| Manufacturer | True Manufacturing |
|---|---|
| Model Number | GDM-10PT-HC~TSL01 |
| Series | GDM Glass Door Merchandiser |
| Quantity | 1/Each |
| Version | True Standard Look Version 01 |
| Width | 24-7/8 Inches |
| Depth | 25-1/2 Inches |
| Height | 53-3/8 Inches |
| Depth Note | Add 1-5/8" each side for door handles |
| Voltage | 115 Volts |
| Hertz | 60 Hz |
| Phase | 1 |
| Amps | 2.2 Amps |
| Plug Type | NEMA 5-15P |
| Cord Length | 10 ft. |
| Circuit | Dedicated 15 Amp Outlet |
| Temperature Range | 33 - 38 Degrees F |
| Refrigerant | R290 (Hydrocarbon) |
| Horsepower | 1/5 HP |
| Compressor Location | Bottom Mount |
| System | Self-Contained, Capillary TubeECM Evaporator and Condenser Fan MotorsEpoxy-Coated Evaporator |
| Doors | 1 Front and 1 Rear Glass Swing Doors, Self-ClosingLow-E Double-Pane Glass |
| Shelves | 3 Adjustable PVC-Coated Wire Shelves, 20-5/8" L x 17-1/2" D |
| Exterior | Black Powder-Coated Cold Rolled Steel |
| Interior | White Aluminum LinerStainless Steel Floor |
| Insulation | Foamed-In-Place High Density Polyurethane |
| Legs | Leg Levelers |
| Lighting | LED Interior Lighting |
| Signage | Door Sign Decal |
| Certifications | cULus, UL EPH Classified |
| Sanitation | NSF/ANSI Standard 7 for Packaged or Bottled Product |
