True TBB-4PT-HC 90" 6-Door (3 Front, 3 Rear) Solid Door Pass-Thru Back Bar Cooler, Black, 152 Six-Packs, R290, 115V
A 90" back bar cooler that keeps beer and mixers at 33°F to 38°F within reach of the bartender from both sides.
The True TBB-4PT-HC is a 90" black back bar cooler with three solid doors on each side (pass-thru). It holds 33°F to 38°F and stands 37" tall, with a stainless steel countertop on top. True rates it at 152 six-packs of 12 oz. cans, or 4 half barrels. It plugs into a dedicated 115V, 15 amp outlet with the included NEMA 5-15P cord.
Measure your bar opening and every doorway on the delivery path; the smallest outside dimension is the 31" cabinet depth.
A factory-balanced, self-contained system keeps the cabinet at 33°F to 38°F.
True rates it at 152 six-packs of 12 oz. cans, or 4 half barrels.
True uses natural R290 hydrocarbon refrigerant in a factory engineered, self-contained capillary tube system.
True's self-cleaning RCU technology removes the need to clean the condenser coil and helps hold temperature.
Electronically commutated fan motors run cooler and use less energy than standard motors.
True rates it at 152 six-packs of 12 oz. cans, or 4 half barrels.
The cabinet is 37" tall. Measure the clear height under your bar top before you order.
A dedicated 115V, 15 amp outlet. It draws 2.9 A and comes pre-wired with a 10 ft. cord and NEMA 5-15P plug.
True rates the TBB-4PT-HC to hold 33°F to 38°F.
Yes, as factory options: 6" legs, 6" seismic/flanged legs, or 2-1/2" or 4" castors. Ask us before you order.
True's self-cleaning RCU technology removes the need to clean the condenser coil.
Yes. True products carry our Best Price Guarantee. Found it lower? Send us the lower price with a quote request or call us, and we will match it.
Specs
| Manufacturer | True Manufacturing |
|---|---|
| Model Number | TBB-4PT-HC |
| Series | Back Bar Cooler (TBB) |
| Quantity | 1/Each |
| Shipping Weight | 545 lb. |
| Width | 90-3/8 Inches |
| Depth | 31 Inches |
| Height | 37 Inches |
| Voltage | 115 Volts |
| Hertz | 60 Hz |
| Phase | 1 |
| Amps | 2.9 Amps |
| Plug Type | NEMA 5-15P |
| Cord Length | 10 ft. |
| Circuit | Dedicated 15 Amp Outlet |
| Temperature Range | 33 - 38 Degrees F |
| Refrigerant | R290 (Hydrocarbon) |
| Horsepower | 1/4 HP |
| System | Self-Contained, Capillary TubeSelf-Cleaning RCU CondenserECM Evaporator and Condenser Fan Motors |
| 12 oz. Cans | 152 Six-Packs |
| Kegs | 4 half barrels |
| Doors | 3 Front and 3 Rear Solid Swing Doors, Pass-ThruLocks Standard |
| Shelves | 6 Adjustable PVC-Coated Wire Shelves |
| Exterior | Black, powder coated cold-rolled steel with stainless steel countertop |
| Lighting | LED Interior Lighting |
| True Options | 6" Legs6" Seismic Legs2-1/2" or 4" CastorsAdditional Shelves |
| Certifications | cULus, UL EPH Classified |
| Sanitation | NSF/ANSI Standard 7 Compliant for Packaged or Bottled Product |
