True TCIM-622-LA1-A 22" Air-Cooled Modular Large Cube Ice Machine Head, 600 lb/24 hr, R290, 115V
An air-cooled modular ice machine that makes up to 600 lb of large cube ice a day.
The True TCIM-622-LA1-A is a 22.25" air-cooled modular ice machine head that makes up to 600 lb of large cube ice per 24 hours at 70°F air and 50°F water, and 480 lb at 90°F air and 70°F water. It runs on R290 refrigerant and has a TrueTouch touchscreen with real-time ice level monitoring. It sits on a separate storage bin, sold separately, and connects to a 115V circuit with a 15 amp minimum circuit ampacity.
The bin is sold separately; plan floor space and height for the bin plus this head.
Rated at 600 lb per 24 hours at 70°F air and 50°F water, and 480 lb at 90°F air and 70°F water.
Makes large cubes, 1-1/8" x 1-1/8" x 7/8".
A 4.3" touchscreen shows ice level, system status and diagnostics in plain language, with ice production scheduling and visual, audible and push alerts.
The sealed TrueNcapsuL8 evaporator inhibits mold, bacteria and biofilm behind the plate; TrueGuard antimicrobial is built into molded parts, and one-touch cleaning plus tool-free parts speed upkeep.
Uses 4.9 oz of natural R290 refrigerant with a micro-channel condenser and a removable air filter, and True says it exceeds ENERGY STAR standards by up to 37%.
Built-in high- and low-pressure transducers let a technician diagnose the system without external gauges.
No. This is the ice machine head only; the storage bin is sold separately. True's spec sheet shows the TCIM-622 on a TIB-422 bin.
Up to 600 lb per 24 hours at 70°F air and 50°F water, and 480 lb at 90°F air and 70°F water.
A 115V, 60 Hz, single phase circuit with a 15 amp minimum circuit ampacity, wired to the junction box.
A 1/2" female NPT potable water inlet at 20 to 100 psi and a 3/4" female NPT water outlet. Water temperature must stay between 35°F and 100°F.
Air-cooled units need 6" on the left, right and back for air intake and exhaust. Room air must stay between 35°F and 110°F.
True's spec sheet shows 3 years parts and labor, 5 years parts only on the compressor, and 5 years parts and labor on the evaporator.
Yes. True products carry our Best Price Guarantee. Found it lower? Send us the lower price with a quote request or call us, and we will match it.
Specs
| Manufacturer | True Manufacturing |
|---|---|
| Model Number | TCIM-622-LA1-A |
| Series | True Ice Series |
| Quantity | 1/Each |
| Shipping Weight | 184 lb. |
| Width | 22.25 Inches |
| Depth | 24.60 Inches |
| Height | 27.19 Inches |
| Clearance | 6" Left, Right and Back for Air Intake and Exhaust |
| Ice Type | Large Cube, 1-1/8" x 1-1/8" x 7/8" |
| Production at 70°F Air / 50°F Water | 600 lb per 24 Hours |
| Production at 90°F Air / 70°F Water | 480 lb per 24 Hours |
| Water Use | 15 gal per 100 lb of Ice at 90°F Air / 70°F Water |
| Energy Use | 4.70 kWh per 100 lb of Ice at 90°F Air / 70°F Water |
| Storage Bin | Not Included, Sold Separately |
| Voltage | 115 Volts |
| Hertz | 60 Hz |
| Phase | 1 |
| Minimum Circuit Ampacity | 15 Amps |
| Connection | Junction Box, 104-127 VAC/60Hz/1 |
| Refrigerant | R290 (Hydrocarbon), 4.9 oz |
| Condenser | Air-Cooled, Micro-ChannelRemovable Air Filter and RCU Technology |
| Peak Heat of Rejection | 8,500 BTU/hr |
| Water Inlet | 1/2" Female NPT, Potable Water |
| Water Outlet | 3/4" Female NPT |
| Ambient Air Temperature | 35 - 110 Degrees F |
| Water Temperature | 35 - 100 Degrees F |
| Water Pressure | 20 - 100 psi |
| Exterior | TrueTech Clear-Coated, Corrosion and Fingerprint Resistant |
| Controls | TrueTouch 4.3" TouchscreenTime-of-Flight Ice Level MonitoringProduction SchedulingGauge-Free Diagnostics |
| True Accessories | TrueZone Ozone Air Purification DeviceTrue Platinum and Standard Water Filter Kits |
| Certifications | ENERGY STAR, cULus |
| Warranty | 3-Year Parts and Labor5-Year Parts Only on Compressor5-Year Parts and Labor on Evaporator |
