True TDM-DC-77-GE/GE-W-W 77" Curved Glass Dry Bakery Display Case, Glass Ends, White Exterior, 3 Shelves, 115V
A 77" curved glass dry case for pastries, breads and baked goods that don't need refrigeration.
The True TDM-DC-77-GE/GE-W-W is a 77" True Display Merchandiser with a curved glass front, glass ends, a white exterior and a white interior. It is a dry, non-refrigerated case, built as a companion to True's refrigerated TDM-R cases. 3 adjustable wire shelves on three levels sit under safety-shielded LED lighting, and staff load from the back through two sliding glass doors. It plugs into a dedicated 115V, 15 amp outlet.
Measure every doorway and turn on the delivery path; the smallest outside dimension is the 39" depth.
A dry case for products that don't need refrigeration, designed as a matching companion to True's refrigerated case.
Curved front and side panels are single pane tempered glass. The front glass swings up for cleaning and full front access.
Heavy-duty wire cantilever shelves on three levels hold up to 150 lb. each and match the interior color; stainless units get chrome-plated shelves.
Two rear sliding glass doors with 12" aluminum handles ride on a stainless steel V-channel with stainless bearings.
Safety-shielded LED interior lighting spreads light evenly across the case.
A dedicated 115V, 15 amp outlet. The case draws 7.0 A and comes pre-wired with an 8 ft. cord and NEMA 5-15P plug.
The case is 77-1/4" wide, 39" deep and 49-1/8" tall. Measure the doorway and every turn on the way in; the smallest outside dimension is the 39" depth.
No. True builds it as a dry case; the sheet lists no compressor or temperature range. It is designed as a companion to True's refrigerated case of the same style, and banked units keep a 1/2" gap.
3 adjustable shelves, up to 150 lb. each. True says the cabinet holds eight 18" x 26" display pans, with other pan mixes listed on the spec sheet; pans are not included.
Staff load and serve from the back through two sliding glass doors. The front glass swings up for cleaning and full front access.
Exterior and interior come in black, white or stainless steel under different model numbers. White, black, chrome, glass or mezzanine shelves and castors or legs are factory options.
Yes. True products carry our Best Price Guarantee. Found it lower? Send us the lower price with a quote request or call us, and we will match it.
Specs
| Manufacturer | True Manufacturing |
|---|---|
| Model Number | TDM-DC-77-GE/GE-W-W |
| Series | TDM True Display Merchandiser, Curved Glass, Glass End |
| Quantity | 1/Each |
| Shipping Weight | 685 lb. |
| Width | 77-1/4 Inches |
| Depth | 39 Inches |
| Height | 49-1/8 Inches |
| Banking Note | 1/2" Gap Remains Between Banked Units Because of Side Panel |
| Voltage | 115 Volts |
| Hertz | 60 Hz |
| Phase | 1 |
| Amps | 7.0 Amps |
| Plug Type | NEMA 5-15P |
| Cord Length | 8 ft. |
| Circuit | Dedicated 15 Amp Outlet |
| Refrigeration | Dry Case, Not Refrigerated, No Compressor Listed |
| Front Glass | Curved Single Pane Tempered Glass, Swings Up for Cleaning |
| End Panels | Clear Glass Ends with Black Trim |
| Rear Doors | 2 Sliding Glass Doors, 12" Aluminum Handles, Stainless Steel V-Channel and Bearings |
| Shelves | 3 Adjustable Heavy-Duty Wire Cantilever Shelves, 3 Levels, 150 lb. Max Each |
| Shelf Finish | Matches Interior ColorChrome Plated Standard on Stainless Units |
| Pan Capacity | 8 Display Pans 18" L x 26" D, Pans Not Included |
| Exterior | White, Rounded Front and Back |
| Interior | White |
| Lighting | LED Interior Lighting, Safety Shielded |
| Insulation | Foamed-In-Place High Density Polyurethane |
| Base | Welded Steel Frame Rail with Leg Levelers |
| True Options | Glass or Frosted Glass ShelvesRatchet LockElectrical ReceptacleExterior Top and Front Shelf Kits4" or 2-1/2" Castors6" Legs |
| Certifications | cULus, UL EPH Classified |
| Sanitation | NSF/ANSI Standard 2 Compliant for Open Food Product |
