True TVM-48-HC~VM01 47" 2-Door Glass Swing Door Visual Merchandiser Refrigerator, 33-38°F, 8 Shelves, R290, 115V
A 2-door glass merchandiser that keeps drinks and packaged food at 33°F to 38°F in full view.
The True TVM-48-HC~VM01 is a 47-1/4" wide visual merchandiser refrigerator with 2 self-closing glass swing doors. Its bottom-mounted R290 system holds 33°F to 38°F. Inside, 8 adjustable cantilever shelves hold the product, with LED interior lighting and an illuminated sign panel. It plugs into a dedicated 115V, 15 amp outlet with the included NEMA 5-15P cord.
Measure every doorway and turn on the delivery path; the smallest outside dimension is the 29-7/8" cabinet depth.
A factory-balanced, self-contained R290 system holds 33°F to 38°F.
Natural R290 hydrocarbon refrigerant with zero ozone depletion potential. The bottom-mounted condenser coil is easy to reach for cleaning.
8 adjustable cantilever shelves. The "no stoop" bottom shelf sits above the condensing unit.
Safety-shielded LED interior lighting spreads light evenly through the cabinet. An illuminated exterior sign panel is standard. True offers a variety of sign options.
2 self-closing glass swing doors. Exterior: black powder-coated metal.
A dedicated 115V, 15 amp outlet. The unit draws 10.5 A and comes with a 10 ft. cord and NEMA 5-15P plug.
The cabinet is 29-7/8" deep, 47-1/4" wide and 78-5/8" tall. Add 1-3/4" for door handles; 5/8" for rear mechanical components. Measure the doorway and every turn on the way in.
True rates the TVM-48-HC~VM01 to hold 33°F to 38°F.
8 adjustable cantilever shelves. True offers additional shelves as an option.
Yes. The condensing unit sits at the bottom of the cabinet, and True designed the condenser coil to be easy to reach for cleaning.
Yes. True products carry our Best Price Guarantee. Found it lower? Send us the lower price with a quote request or call us, and we will match it.
Specs
| Manufacturer | True Manufacturing |
|---|---|
| Model Number | TVM-48-HC~VM01 |
| Series | TVM Visual Merchandiser |
| Quantity | 1/Each |
| Shipping Weight | 520 lb. |
| Version | Visual Merchandiser Version 01 |
| Width | 47-1/4 Inches |
| Depth | 29-7/8 Inches |
| Height | 78-5/8 Inches |
| Depth Note | Add 1-3/4" for door handles; 5/8" for rear mechanical components |
| Voltage | 115 Volts |
| Hertz | 60 Hz |
| Phase | 1 |
| Amps | 10.5 Amps |
| Plug Type | NEMA 5-15P |
| Cord Length | 10 ft. |
| Circuit | Dedicated 15 Amp Outlet |
| Temperature Range | 33 - 38 Degrees F |
| Refrigerant | R290 (Hydrocarbon) |
| Horsepower | 1/2 HP |
| Compressor Location | Bottom Mount |
| System | Self-Contained, Capillary TubeECM Evaporator and Condenser Fan MotorsEpoxy-Coated Evaporator |
| Doors | 2 Glass Swing Doors, Self-Closing |
| Shelves | 8 Adjustable Cantilever Shelves |
| Exterior | Black Powder-Coated Metal |
| Interior | White Aluminum LinerStainless Steel Floor |
| Insulation | Foamed-In-Place High Density Polyurethane |
| Legs | Leg Levelers |
| Lighting | LED Interior Lighting |
| Signage | Illuminated Sign Panel |
| True Options | 6" standard legs6" seismic/flanged legs4" diameter castorsWhite exteriorStainless exteriorBlack interiorStainless steel interiorFloor rackAdditional shelves |
| Certifications | cULus, UL EPH Classified |
| Sanitation | NSF/ANSI Standard 7 for Packaged or Bottled Product |
