Description
Make full cube ice and store it in one compact unit that fits under the counter.
The Serv-Ware SWUC-80F is a 20" undercounter ice machine for bars, restaurants and cafes. It makes up to 80 lb of full cube ice per 24 hours and keeps about 33 lb in its built-in bin. It plugs into a standard 115V outlet, runs on R290 refrigerant, is Energy Star certified and ETL Sanitation listed, and carries a 3-year parts and labor warranty.
Will it fit · Will it plug in
- Outside size
- 19.76" W × 17.71" D × 36.34" H (on 6.30" legs; cabinet 30.04" H)
- Air flow
- Front intake and exhaust, for undercounter installation
- Storage bin
- Built in; holds about 33 lb of ice
- Power
- 115V, 60 Hz, 1-phase, 390 watts, NEMA 5-15P plug
- Shipping weight
- 88 lbs
Measure every doorway and turn on the delivery path; its smallest outside dimension is the 17.71" depth. Under a counter, check the clear height and width of the opening, and plan a water supply line and a drain.
Up to 80 lb a day
Makes up to 80 lb of full cube ice per 24 hours for bars, restaurants and cafes.
Built-in 33 lb bin
The storage bin holds about 33 lb of ice and comes with a scoop and an internal ice baffle for easier serving.
Made for under the counter
Front air intake and exhaust allow undercounter installation, and adjustable front legs level it on uneven floors.
Air-cooled with R290
A 1/4 HP, 1,330 BTU/h air-cooled system runs on R290 hydrocarbon refrigerant.
Runs on its own
Integrated electronic controls with status indicators, an automatic ice-making cycle, bin-full shutoff, and smart LED lighting with a remote.
Listed for food service
Energy Star, cETLus, ETL Sanitation listed. Conforms to UL 471 and NSF 7 and is certified to CSA C22.2 No. 120.
Delivery and setup
- Free shipping on this item. See our shipping policy for delivery details.
- Usually ships the next business day.
- Covered by our Best Price Guarantee.
- Plan a water supply line and a drain at the install location, and keep the front grilles clear for air flow.
- Level the unit with the adjustable front legs after it is in place.
- Inspect the shipment before signing for it and note any damage with the carrier.
Questions buyers ask
Does it need a separate storage bin?
No. The SWUC-80F has a built-in storage bin that holds about 33 lb of ice, plus an ice scoop and an internal ice baffle.
What outlet does it need?
It runs on 115V, 60 Hz, single phase, is rated at 390 watts and has a NEMA 5-15P plug for a standard wall outlet. Serv-Ware does not publish an amp rating, so ask your electrician whether to give it its own circuit.
Will it fit under my counter?
It is 19.76" wide and 17.71" deep and stands 36.34" high on its 6.30" legs; the front legs adjust for leveling. Air comes in and goes out at the front, which is what lets it work under a counter. Measure the clear height and width of the opening before you order.
How much ice does it make?
Serv-Ware rates it at up to 80 lb of full cube ice per 24 hours. It runs an automatic ice-making cycle and stops when the 33 lb bin is full.
What does the warranty cover?
Serv-Ware covers parts and labor on the entire unit for 3 years and the compressor and evaporator for 5 years (part only), in the United States and for commercial use only.
When will it ship, and do you match lower prices?
Serv-Ware items usually ship the next business day, shipping is free on this item, and it is covered by our Best Price Guarantee. Call (201) 467-8222 if you find a lower price.
Specs
| Manufacturer | Serv-Ware |
|---|---|
| Model Number | SWUC-80F |
| Quantity | 1/Each |
| Shipping Weight | 88 lb. |
| Width | 19.76 Inches |
| Depth | 17.71 Inches |
| Height | 36.34 Inches (with Legs) |
| Cabinet Height | 30.04 Inches (without Legs) |
| Leg Height | 6.30 Inches |
| Legs | Adjustable Front Leveling Legs |
| Voltage | 115 Volts |
| Wattage | 390 Watts |
| Hertz | 60 Hz |
| Phase | 1 Phase |
| Plug Type | NEMA 5-15P |
| Ice Type | Full Cube |
| Ice Production | Up to 80 lb. per 24 Hours |
| Bin Capacity | Approx. 33 lb. (Built-In Storage Bin) |
| Ice-Making Cycle | AutomaticBin-Full Shutoff |
| Included | Ice ScoopInternal Ice BaffleLED Lighting Remote |
| Condenser | Air-Cooled |
| Airflow | Front Intake and Exhaust |
| Refrigerant | R290 (Hydrocarbon) |
| BTU | 1,330 BTU/H |
| Horsepower | 1/4 hp |
| Defrost | Automatic |
| Controls | Integrated Electronic ControlsStatus Indicators |
| Exterior Material | Stainless Steel |
| Interior Material | Food-Grade Polyethylene |
| Insulation | Rigid Polyurethane Foam |
| Structure | Reinforced Heavy Duty Cabinet |
| Lighting | Smart LED LightingRemote Included |
| Certifications | Energy Star, cETLus, ETL Sanitation |
| Standards | Conforms to UL 471 and NSF 7Certified to CSA C22.2 No. 120 |
| Warranty | 3 Years Parts & Labor5 Years Compressor & Evaporator (Part Only) |
| Usage | Commercial Use |
