Unity BLU-22SB 22" Black Single Swing Glass Door Merchandiser Refrigerator, 7.27 cu. ft., LED, 32-50°F, 110V
A slim black glass door cooler that shows bottled and canned drinks at eye level.
The Unity BLU-22SB is a single swing glass door merchandiser refrigerator for cafes, delis, convenience stores and offices that sell cold drinks. It holds 7.27 cu. ft. at 32°F to 50°F on 3 adjustable PVC-coated shelves, lit by vertical LED lights, with a bottom mounted refrigeration system. At 21.14" wide it fits narrow spots, and it plugs into a 110V NEMA 5-15P outlet (1.73 A) on a dedicated 15 A circuit.
Measure every doorway and turn on the delivery path; the smallest outside dimension is the 19.17" depth.
Three adjustable shelves and vertical LED lights put bottles and cans on show.
21.14" wide and 19.17" deep for tight counters and aisles.
Digital controls set 32°F to 50°F.
A magnetic door gasket and recessed handle.
A standard 110V NEMA 5-15R outlet for its NEMA 5-15P plug (85" cord). It draws 1.73 A (180 W). USR Brands asks for a dedicated 15 A circuit installed by a licensed electrician, so do not share the outlet or use an extension cord.
7.27 cu. ft. on 3 adjustable PVC-coated steel shelves, each 16.73" L x 13.13" D. Space them to fit cans, bottles or tall drinks.
The swing glass door reaches 39.84" from the back of the cabinet when open (drawing), so leave that much clear floor in front.
Digital controls set 32°F to 50°F, the range for drinks and packaged cold food on display.
It measures 21.14" W x 19.17" D x 61.1" H and ships in a 23.23" L × 21.06" D × 63.58" H carton at 185 lb. The smallest outside dimension is the 19.17" depth; measure every doorway on the delivery path.
The BLU-22SB is not named in either current Unity warranty statement (REV 01-2026), so call us to confirm the warranty terms before ordering.
Specs
| Manufacturer | Unity (USR Brands) |
|---|---|
| Model Number | BLU-22SB |
| Quantity | 1/Each |
| Shipping Weight | 185 lb. |
| Net Weight | 146 lb. |
| Width | 21.14 Inches |
| Depth | 19.17 Inches |
| Height | 61.1 Inches |
| Depth with Door Open | 39.84 Inches |
| Interior Dimensions | 17.48" L x 14.96" D x 53.82" H |
| Packaging Dimensions | 23.23" L x 21.06" D x 63.58" H |
| Capacity | 7.27 cu. ft. |
| Voltage | 110 Volts |
| Amps | 1.73 Amps |
| Hertz | 60 |
| Phase | 1 |
| Wattage | 180 W |
| Plug Type | NEMA 5-15P |
| Power Cord Length | 85" |
| Electrical Requirement | Dedicated 15 Amp Circuit, Installed by a Licensed Electrician |
| Temperature Range | 32 - 50 Degrees F |
| Refrigerant | Hydrocarbon |
| Controls | Digital |
| Type | Glass Door Merchandiser Refrigerator |
| Door | 1 Swing Glass DoorRecessed HandleMagnetic Gasket |
| Shelves | 3 Adjustable PVC-Coated Steel16.73" L x 13.13" D |
| Lighting | Vertical LED |
| Exterior | Black Painted Steel |
| Interior | Coated Sheet |
| Insulation | Foamed-in-Place Polyurethane |
| Refrigeration System | Bottom Mounted |
| Base | 2 Front Feet, 2 Rear Casters |
| Certifications | cETLusETL Sanitation |
