Description
A 23" single-door back bar cooler that fits into a tight spot behind the bar and keeps drinks cold out of sight.
Built for bars, restaurants, cafés and hotel bars, the Atosa MBB23GR gives you 8.2 cu. ft. of storage behind one lockable solid door, held at 35°F to 38°F. It is stainless steel inside and out, runs on a standard 115V outlet (2.3 amps), and stands 38-3/4" tall on pre-installed casters.
Will it fit · Will it plug in
- Outside size
- 23" W × 31-1/8" D × 38-3/4" H (with casters)
- Power
- 115V, 60 Hz, 1-phase, 2.3 amps; NEMA 5-15P plug
- Shipping weight
- 207 lb. (170 lb. net)
Measure every doorway and turn on the delivery path; the smallest outside dimension is the 23" width. Leave room around the unit for air flow and keep the condenser clean. The rear lower skirt extends 3-3/4" down behind the casters, so the casters on this model cannot be removed.
Built for the back bar
At 38-3/4" tall and 23" wide it fits under a typical back bar counter, and the solid door hides stock and holds cold well during busy service.
Easy compressor service
The Embraco compressor sits on a slide-out assembly, so a technician can reach it without pulling the whole cabinet.
Lockable door
The door has a lock and a magnetic gasket, so stock stays secure after close.
Stainless inside and out
Stainless steel cabinet and interior with 2 epoxy-coated shelves that resist rust in a cold, humid cabinet.
Delivery and setup
- Free shipping on this item. See our shipping policy for delivery details.
- Usually ships in 1 business day.
- Covered by our Best Price Guarantee: call (201) 467-8222 if you find a lower price.
- Ships by freight with the casters already installed (2 of the 4 lock).
- Keep the unit upright, and inspect it for damage before signing for the delivery.
- Atosa recommends cleaning the condenser regularly to keep it cooling well.
Questions buyers ask
What outlet does it need?
A standard 115V grounded outlet for the NEMA 5-15P plug. It draws 2.3 amps. Do not use an extension cord: Atosa's warranty does not cover damage from extension cords, low voltage or voltage drops.
Will it fit through my door?
The cooler is 23" wide, 31-1/8" deep and 38-3/4" tall with casters, so its narrowest side is the 23" width. Measure doorways and turns before delivery.
What temperature does it hold?
Atosa specifies 35°F to 38°F, which suits beer, soda, wine and other packaged drinks. It is made to keep drinks and packaged products cold, not to chill hot food.
What does the warranty cover?
Atosa's 2026 refrigeration warranty gives 3 years parts and labor and 5 years on the sealed compressor parts, counted from shipment from Atosa. Keep your invoice; claims go through Atosa with the model and serial number.
Is there a glass door version?
Yes. The Atosa MBB23GGR is the same 23" size with glass door (8.2 cu. ft.).
Do you match lower prices?
Yes. Atosa products are covered by our Best Price Guarantee. Call (201) 467-8222 with the lower price.
Specs
| Manufacturer | Atosa |
|---|---|
| Model Number | MBB23GR |
| Quantity | 1/Each |
| Shipping Weight | 207 lb. |
| Net Weight | 170 lb. |
| Width | 23 Inches |
| Depth | 31-1/8 Inches |
| Height | 38-3/4 Inches (with casters) |
| Cabinet Depth | 29-1/2 Inches (31-1/8 Inches overall) |
| Caster Size | 3.5 Inches |
| Voltage | 115 Volts |
| Amps | 2.3 Amps |
| Hertz | 60 Hz |
| Phase | 1 Phase |
| Plug Type | NEMA 5-15P |
| Capacity | 8.2 cu. ft. |
| Temperature Range | 35 - 38 Degrees F |
| Horsepower | 1/7 hp |
| Refrigerant | R290 (Hydrocarbon) |
| Compressor | EmbracoSlide-Out Compressor Assembly |
| Refrigeration Type | Self-Contained |
| Controls | Electronic Temperature Controller |
| Exterior Material | Stainless Steel |
| Interior Material | Stainless Steel |
| Access Type | Door |
| Number of Doors | 1 |
| Door Type | Solid |
| Door Style | Swing |
| Door Features | Door LockMagnetic GasketRecessed HandleInterior Light |
| Number of Shelves | 2 (Epoxy-Coated) |
| Casters | Pre-Installed2 with Brakes |
| Certifications | ETL Sanitation, cETLus |
| Warranty | 3 Years Parts & Labor5 Years Compressor (Part Only) |
| Usage | Commercial Indoor Use |
