Description
A one-section pass-thru refrigerator: stock it from the back of house and let staff or customers reach it through the glass front door.
The Atosa PLUS-R1-GS-R-PT has a double-pane glass door on the front and a solid door on the back, so it can sit in a wall opening or between prep and service areas. It holds 23.7 cu. ft. at 35°F to 38°F on four shelves, runs on a standard 115V outlet (3.7 amps), and rolls on pre-installed 4" casters. The front door is hinged on the right; the PLUS-R1-GS-L-PT is the left-hinged version.
Will it fit · Will it plug in
- Outside size
- 28-3/4" W × 33-7/8" D × 82-7/8" H (with 4" casters; cabinet 78" + 4-7/8")
- Door swing
- Front and rear doors open to 105°; plan view shows about 29-3/8" of swing on each side
- Inside
- About 24" W × 25" D × 59-5/8" H (Atosa drawing)
- Power
- 115V, 60 Hz, 1-phase, 3.7 amps; NEMA 5-15P plug
- Shipping weight
- 357 lb. (313 lb. net)
Measure every doorway and turn on the delivery path; the smallest outside dimension is the 28-3/4" width, and it is 82-7/8" tall on casters. Leave clear space at both doors for the 105° swing. Atosa asks for room around the unit to breathe; it publishes no exact clearance.
Two-way access
Glass front door for display and grab-and-go, solid rear door for restocking from the kitchen side.
Even cooling
A down-duct airflow channel spreads cold air through the cabinet; the electronic controller holds 35°F to 38°F.
Secure and visible
Door locks are standard, and LED lights show the contents through the double-pane glass.
Doors that stay put
Self-closing doors with a stay-open feature and magnetic gaskets.
Delivery and setup
- Free shipping on this item. See our shipping policy for delivery details.
- Usually ships in 1 business day.
- Covered by our Best Price Guarantee: call (201) 467-8222 if you find a lower price.
- Ships by freight with the 4" casters pre-installed; inspect it for damage before signing for the delivery.
- Shelf clips are pre-installed.
Questions buyers ask
What outlet does it need?
A grounded 115V outlet for the NEMA 5-15P plug. It draws 3.7 amps.
Which side is the door hinged on?
The front glass door is hinged on the right (handle on the left), per the Atosa drawing. Atosa sells the left-hinged version as PLUS-R1-GS-L-PT.
Are both doors glass?
No. The front door is double-pane glass and the rear door is solid. Atosa's PLUS-F2B-GD-S-PT is the 2-section model with glass on both sides.
Will it fit through my doorway?
Its narrowest dimension is the 28-3/4" width, and it is 82-7/8" tall on the casters. Measure your doors and hallways before ordering.
How cold does it get?
Atosa rates it to hold 35°F to 38°F and recommends setting it in that range.
What does the warranty cover?
Atosa gives 3 years parts and labor and 5 years on the compressor (parts only for the extra 2 years). The 2026 Atosa refrigeration warranty counts from shipment from Atosa; keep your invoice and register the unit.
Do you match lower prices?
Yes. Atosa products are covered by our Best Price Guarantee. Call (201) 467-8222 with the lower price.
Specs
| Manufacturer | Atosa |
|---|---|
| Model Number | PLUS-R1-GS-R-PT |
| Quantity | 1/Each |
| Shipping Weight | 357 lb. |
| Net Weight | 313 lb. |
| Width | 28-3/4 Inches |
| Depth | 33-7/8 Inches |
| Height | 82-7/8 Inches (with 4" casters) |
| Cabinet Height | 78 Inches |
| Interior Dimensions | 24 W x 25 D x 59-5/8 H Inches (drawing) |
| Door Swing | 105 Degrees |
| Caster Size | 4 Inches |
| Voltage | 115 Volts |
| Amps | 3.7 Amps |
| Hertz | 60 Hz |
| Phase | 1 Phase |
| Plug Type | NEMA 5-15P |
| Capacity | 23.7 cu. ft. |
| Temperature Range | 35 - 38 Degrees F |
| Horsepower | 1/3 hp |
| Compressor | Cubigel |
| Refrigerant | R290 (Hydrocarbon) |
| Refrigeration Type | Self-Contained, Top Mount |
| Airflow | Down-Duct Air Channel |
| Controls | Full Electronic Controller |
| Exterior Material | Stainless Steel |
| Interior Material | Stainless Steel |
| Sections | 1 |
| Number of Doors | 2 (Pass-Thru) |
| Door Type | Front: Double-Pane GlassRear: Solid |
| Hinge | Right (Front Door) |
| Door Features | Self-Closing with Stay-Open FeatureMagnetic GasketDoor Locks |
| Number of Shelves | 4 (Epoxy-Coated) |
| Lighting | LED Interior Lights |
| Casters | Pre-Installed 4" Casters |
| Certifications | ETL Sanitation, cETLus |
| Warranty | 3 Years Parts & Labor5 Years Compressor (Part Only) |
| Usage | Commercial Indoor Use |
