Coldline CF76 76" Commercial Chest Freezer, Solid Hinged Lid, 22.5 cu. ft., White, -8 to -0.4°F, 115V
A 22.5 cu. ft. commercial chest freezer for ice cream, patties and frozen stock in shops, kitchens and markets.
The Coldline CF76 is a white chest freezer for ice cream shops, concession stands, restaurants, markets and convenience stores. It holds 22.5 cu. ft. at -8°F to -0.4°F under a solid hinged lid with a lock, with 2 wire baskets for small items. It rolls on casters with brakes and plugs into a standard 115V NEMA 5-15P outlet on a dedicated 15 A circuit.
Measure every doorway and turn on the delivery path; its smallest outside dimension is the 30.5" depth.
A manual knob sets the temperature; manual defrost with a drain plug.
2 coated wire baskets keep small items within reach.
6 casters, 3 with brakes.
R290 hydrocarbon refrigerant and foamed-in-place insulation.
It runs on 115V, 60 Hz, single phase and draws 4.8 A. It has a NEMA 5-15P plug on a 72" cord, and Coldline requires a dedicated 15 A circuit installed by a licensed electrician.
The Coldline sheet gives -8°F to -0.4°F. The manual says to let it run until it reaches about 0°F before loading food, then fine-tune the knob after 12 hours; a higher number on the knob means colder.
Defrost is manual. The manual says to defrost when the frost layer reaches about 1/5" (5 mm): switch it off, empty it, leave the lid open and drain the water through the drain plug at the bottom. Do not scrape the frost with metal tools.
It is 76.25" wide, 30.5" deep and 33" high. The manual asks for more than 10 cm (about 4") of space at the front and back walls, a level floor, good ventilation and a room no warmer than 100°F, out of direct sun.
Yes, the lid has a lock.
USR Brands covers the Coldline CF-Series chest freezers for 1 year parts and labor from delivery, in the contiguous US. Food truck and farm installs are covered for parts only, and residential use is not covered.
The Coldline one-year warranty states that USR Brands cannot ship to or guarantee its products in CA, OR, WA, MT, WY or UT. Call us before ordering for one of those states.
Specs
| Manufacturer | Coldline (USR Brands) |
|---|---|
| Model Number | CF76 |
| Quantity | 1/Each |
| Shipping Weight | 209 lb. |
| Net Weight | 165 lb. |
| Width | 76.25 Inches |
| Depth | 30.5 Inches |
| Height | 33 Inches |
| Packaging Dimensions | 79" L x 34" D x 33.5" H |
| Voltage | 115 Volts |
| Amps | 4.8 Amps |
| Hertz | 60 |
| Phase | 1 |
| Plug Type | NEMA 5-15P |
| Power Cord Length | 72 Inches |
| Circuit | Dedicated 15 Amp, Installed by a Licensed Electrician |
| Capacity | 22.5 cu. ft. |
| Temperature Range | -8 - -0.4 Degrees F |
| Refrigerant | R290 |
| Horsepower | 1/2 HP |
| Defrost | ManualDrain Plug |
| Controls | Manual Knob |
| Lid | Solid, Hinged, Flat Top |
| Lock | Yes |
| Baskets | 2 Coated Wire, 21.46" L x 10.43" D x 10.27" H |
| Interior Lighting | No |
| Exterior | White Powder Coated Steel |
| Interior | Embossed Aluminum |
| Insulation | Foamed-in-Place Polyurethane |
| Casters | 6, 3 with Brakes |
| Certifications | cETLusETL Sanitation |
| Warranty | 1 Year Parts & Labor |
