Coldline SD34 34" Flat Glass Top Ice Cream Display Freezer, 7 cu. ft., 2 Baskets, -14.8 to -0.4°F, 115V
A 34" flat glass top freezer that puts ice cream and frozen treats on show at the counter.
The Coldline SD34 is a glass top display freezer for convenience stores, delis, cafes and concession stands. It holds 7 cu. ft. at -14.8°F to -0.4°F in 2 coated wire baskets under two sliding Low-E tempered glass lids with a built-in lock. It plugs into a standard 115V outlet with a NEMA 5-15P plug on a dedicated 15 amp circuit and rolls on four low-profile casters, two with brakes.
Measure every doorway and turn on the delivery path; its smallest outside dimension is the 21.3" depth. Coldline says not to tilt it more than 60° while moving it.
Flat glass top with sliding Low-E tempered lids shows the product and keeps the cold in.
2 coated wire baskets, each 16.77" L x 7.87" D x 7.28" H keep pints, bars and novelties organized.
Manual control holds -14.8°F to -0.4°F with R290 refrigerant.
4 low-profile casters, 2 with brakes, plus a rear drain plug for defrosting.
A grounded 115V outlet for the NEMA 5-15P plug. USR Brands says it needs a dedicated 15 amp circuit installed by a licensed electrician.
It is 33.9" wide, 21.3" deep and 33.1" tall. The Coldline manual asks for more than 10 cm (about 4") between the freezer and the wall, in a dry, ventilated spot out of direct sun and away from heat sources.
Coldline rates it at -14.8°F to -0.4°F. It is meant for ice cream and other frozen desserts, not for bottled or canned drinks.
Defrosting is manual. When the frost layer reaches about 5 mm (1/5"), switch it off, take out the product, open the lids and let it melt, then drain the water through the rear drain plug.
USR Brands covers SD-Series freezers for 1 year parts and labor from delivery, in the contiguous US. Glass is not covered, so refuse a delivery with broken glass. Food truck and farm installs are parts only; residential use is not covered.
The Coldline warranty states that USR Brands cannot ship to or guarantee its products in CA, OR, WA, MT, WY or UT. Call us before ordering for one of those states.
Specs
| Manufacturer | Coldline (USR Brands) |
|---|---|
| Model Number | SD34 |
| Quantity | 1/Each |
| Shipping Weight | 90 lb. |
| Width | 33.9 Inches |
| Depth | 21.3 Inches |
| Height | 33.1 Inches |
| Packaging Dimensions | 37" L x 24" D x 35" H |
| Voltage | 115 Volts |
| Hertz | 60 |
| Phase | 1 |
| Plug Type | NEMA 5-15P |
| Circuit | Dedicated 15 Amp Circuit |
| Capacity | 7 cu. ft. |
| Temperature Range | -14.8 to -0.4 Degrees F |
| Refrigerant | R290 |
| Defrost | ManualRear Drain Plug |
| Temperature Control | Manual |
| Top Style | Flat Glass |
| Lids | 2 Sliding Low-E Tempered Glass |
| Lock | Built-in |
| Lid Frame Color | Silver |
| Baskets | 2 coated wire baskets, each 16.77" L x 7.87" D x 7.28" H |
| Exterior | White Painted SteelWhite Plastic Trim |
| Interior | Embossed Aluminum |
| Insulation | Foamed-in-Place Polyurethane |
| Casters | 4 Low-Profile2 with Brakes, 2 without |
| Certifications | cETLusETL Sanitation |
| Warranty | 1 Year Parts & Labor |
| Usage | CommercialIce Cream and Frozen Desserts |
