Description
A 23-1/2" undercounter ice machine that makes and stores ice right where the bar or service station needs it.
The Atosa YR140-AP-161 makes up to 142 lb. of half-diced cube ice a day and keeps 88 lb. in its built-in bin, so a bar, cafe or small restaurant does not need a separate ice bin. It fits under a counter or stands alone, plugs into a standard 115V outlet and comes with a 3M water filter system.
Will it fit · Will it plug in
- Outside size
- 23-1/2" W × 28-1/2" D × 38-3/5" H (height includes leg levelers)
- Power
- 115V, 60 Hz, 1-phase, 3.1 amps; NEMA 5-15P plug
- Water and drain
- Cold water supply and a drain are required; inlet accepts 3/8" OD tubing, 3/4" hose barb outlet (bin drain built into the outlet)
- Ice
- 142 lb. per 24 hours; 88 lb. bin
- Shipping Weight
- 176 lb.
Measure every doorway and turn on the delivery path before ordering, and plan the water line, drain and outlet.
All in one
Up to 142 lb. of ice a day with 88 lb. of storage in the same cabinet.
Half-diced cubes
3/8" x 7/8" x 7/8" cubes cool drinks fast and pack well in a glass.
Filter included
A 3M water filter system comes standard; Atosa recommends a new cartridge about every 6 months.
Easy upkeep
Removable air filter and a power switch you can reach without removing panels.
Delivery and setup
- Free shipping on this item. See our shipping policy for delivery details.
- Usually ships in 1 business day.
- Covered by our Best Price Guarantee: call (201) 467-8222 if you find a lower price.
- Ships by freight on a pallet.
- Inspect the cabinet for damage before signing for the delivery.
- A plumber should connect the water supply and drain; install the 3M water filter that comes with it.
Questions buyers ask
What outlet does it need?
A grounded 115V outlet for the NEMA 5-15P plug; it draws 3.1 amps. Do not use an extension cord.
Does it need a floor drain?
Yes. Atosa says it requires a drain. Plan a gravity drain near the unit before delivery, plus a cold water line.
Does it need a water filter?
Atosa includes a 3M water filter system and says every Atosa ice machine should run with it installed. Replace the cartridge about every 6 months, more often with hard water.
Can I build it in under a counter?
Atosa lists it for freestanding or built-in use. It is 38-3/5" tall including the leg levelers; measure the opening and leave room for airflow.
What does the warranty cover?
Atosa's 2026 ice machine warranty gives 2 years parts and labor and 5 years on the sealed compressor (parts only after year 2), counted from shipment. Cleaning and maintenance are not covered, and Atosa expects the included 3M water filter to be installed.
Do you match lower prices?
Yes. Atosa products are covered by our Best Price Guarantee. Call (201) 467-8222 with the lower price.
Specs
| Manufacturer | Atosa |
|---|---|
| Model Number | YR140-AP-161 |
| Quantity | 1/Each |
| Shipping Weight | 176 lb. |
| Width | 23-1/2 Inches |
| Depth | 28-1/2 Inches |
| Height | 38-3/5 Inches |
| Voltage | 115 Volts |
| Amps | 3.1 Amps |
| Watts | 363 Watts |
| Hertz | 60 Hz |
| Phase | 1 Phase |
| Plug Type | NEMA 5-15P |
| Ice Production | Up to 142 lb. per 24 Hours |
| Storage Capacity | 88 lb. |
| Ice Type | Half-Diced Cube, 3/8 x 7/8 x 7/8 Inches |
| Energy Use | 6.13 kWh per 100 lb. of Ice |
| Condenser | Air Cooled |
| Refrigerant | R290 |
| Exterior | Stainless Steel |
| Water Filter | 3M Water Filter System Included |
| Drain | Required |
| Water Connections | 3/8" Slip Inlet (3/8" OD Tubing)3/4" Hose Barb Outlet (Bin Drain Built In) |
| Legs | 6 Inch Legs (Height Includes Leg Levelers) |
| Bin Door | Slanted Blue Plastic |
| Ice Scoop | Included |
| Installation | Freestanding or Built-In |
| Certifications | ETL Sanitation, cETLus, Energy Star (Atosa sheet) |
| Standards | UL 471, CSA C22.2 No. 120 |
| Warranty | 2 Years Parts & Labor5 Years Compressor (Part Only) |
| Usage | Commercial Indoor Use |
